Allen-Bradley 20AD011A0AYNANNN
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice, here.
Allen-Bradley 20AD011A0AYNANNN
The Allen-Bradley 20AD011A0AYNANNN, a component of the PowerFlex 70 series engineered by Rockwell Automation, is optimized for high-performance operation in diverse industrial settings. This alternating current (AC) drive unit is specifically designed for environments with spatial constraints, providing reliable speed and torque regulation..
Technical Features:
The 20AD011A0AYNANNN, part of the PowerFlex 70 series, features a Frame Size C, which is designed to accommodate the drives compact and efficient design.
The enclosure of the 20AD011A0AYNANNN is designed for panel mounting and complies with IP 20 and NEMA/UL Type 1 standards. This means the drive is protected against solid foreign objects and provides a degree of protection against contact with moving parts.
The interface module of the Allen-Bradley 20AD011A0AYNANNN is equipped with a blank cover. This design choice provides flexibility in terms of future upgrades or customization.
The Allen-Bradley 20AD011A0AYNANNN, a model within the PowerFlex 70 series, is designed with a network type that is categorized as "None." This means that the drive does not come with built-in network communication capabilities.
In terms of control, the 20AD011A0AYNANNN is equipped with standard control features. This encompasses basic but robust functionalities that are sufficient for a wide range of applications.
The "Safe Off" feature is designated as N/A (Not Applicable) for this model. This indicates that the drive does not include a built-in safety mechanism to disconnect power in emergencies rapidly.
Regarding feedback, the 20AD011A0AYNANNN does not have built-in feedback mechanisms. Instead, it offers enhanced control capabilities without direct feedback.
The Allen-Bradley 20AD011A0AYNANNN operates at a 480V AC voltage, making it suitable for high-voltage industrial environments requiring robust and consistent power. This voltage capability ensures that the drive can manage demanding applications, delivering reliable performance and minimizing the risk of power-related issues.
With a current rating of 11 amperes (Amps), the Allen-Bradley 20AD011A0AYNANNN is equipped to handle significant electrical loads. This amperage capacity enables the drive to supply adequate power to motors, ensuring efficient operation even under heavy load conditions.
Operating Conditions:
The 20AD011A0AYNANNN from the PowerFlex 70 series is meticulously engineered to deliver unwavering performance in industrial settings, thriving within a diverse temperature spectrum of 0°C to 50°C (32°F to 122°F). Its robust design ensures that it remains reliable and efficient under varying thermal conditions.
Humidity control is crucial for the Allen-Bradley 20AD011A0AYNANNN, which is designed to function effectively in environments with up to 95% relative humidity and non-condensing.
Advanced Control Capabilities:
The Allen-Bradley 20AD011A0AYNANNN offers excellent speed and torque control along with robust fault-handling capabilities, making it suitable for various motors in both single and multi-motor configurations. It is ideal for standalone applications and can be integrated into new or existing speed control systems. This versatility ensures the drive meets diverse operational requirements while maintaining reliable and efficient performance.
Frequently Asked Questions:
What are the power specifications for the Allen-Bradley 20AD011A0AYNANNN?
The 20AD011A0AYNANNN is rated at 5.5 kilowatts (kW) or 7.5 horsepower (Hp). This power rating allows the drive to support a variety of industrial applications.
What does an IP20 rated enclosure mean for the Allen-Bradley 20AD011A0AYNANNN?
The IP20-rated enclosure of the Allen-Bradley 20AD011A0AYNANNN indicates that the drive is protected against solid objects larger than 12mm, such as fingers or tools, but offers no protection against water ingress.
What are the manual control features of the Allen-Bradley 20AD011A0AYNANNN?
The 20AD011A0AYNANNN features manual control, which provides straightforward and reliable operation for various industrial applications.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | PowerFlex 70 |
| Horsepower | 7.5 HP (Normal Duty), 5 HP (Heavy Duty) |
| Voltage | 480 V AC (3-Phase) |
| Dimensions | 300 mm, Width: 185 mm, Depth: 179.8 mm |
| Efficiency | 97.5% at rated amps |
| Brake IGBT | Yes |
| Ambient Temperature Range | 0 to 50 °C (32 to 122 °F) |
| Control Method | Standard control with sine coded PWM and vector control options |
| Input/Output Frequency Range | Input: 47-63 Hz, Output: 0-400 Hz (standard control), 0-500 Hz (enhanced control) |
| Mounting Type | Panel Mount (IP20 / NEMA Type 1) |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 20AD011A0AYNANNN
| Brand | Allen-Bradley |
|---|---|
| Part Number/Catalog No. | 20AD011A0AYNANNN |
| Voltage | 480V AC |
| Ph | 3 |
| Amps | 11 |
| kW(Hp) | 5.5 (7.5) |
| Frame | C |
| Enclosure | Panel Mount - IP 20, NEMA/UL Type 1 |
| Interface Module | Blank Cover |
| Type | Manual |
| w/Brake | Yes |
| w/Resistor | No |
| Rating | Filtered A & B Frames (Optional) C, D, & D Frames (Standard) |
| Network Type | None |
| Control | Standard |
| Safe Off | N/A |
| Feedback | No Feedback - Enhanced Control |
| UPC | 662453737812 |
