Allen-Bradley 20AD014A0AYNANC0
Allen-Bradley 20AD014A0AYNANC0
The Allen-Bradley 20AD014A0AYNANC0 is a high-performance frequency drive that has been specifically engineered for the most rigorous industrial applications. This drive is an optimal choice for a variety of operational requirements due to its sophisticated control methods, robust features, and adaptable configurations.
Technical Specifications:
The Allen-Bradley 20AD014A0AYNANC0 is compatible with a full-featured LCD Human Interface Module. This module provides multilingual text support for startup, measuring, programming, troubleshooting, and maintenance duties, improving accessibility and ease of use.
The drive is compatible with 3-phase systems and provides an output current of 14 Amperes, with an output voltage range of 0-460 Volts AC. It is equipped with dual output power capabilities, which enable it to generate 10 horsepower during normal operation and 7.5 horsepower during intensive operation.
The drives adaptability guarantees that it can satisfy various operational needs. The input voltage range 20AD014A0AYNANC0 is 380-480 VAC, consistent with conventional industrial power systems. The IP20/IP00 enclosure rating signifies that the drive is safeguarded from substantial objects and can be securely installed in controlled environments.
The drive is designed for 3-phase systems and classified under Frame C, making it appropriate for various applications. Its panel-mount enclosure simplifies installation and integration into existing systems.
Control Methods:
The Allen-Bradley 20AD014A0AYNANC0 drive supports Vector Control with FORCE Technology for enhanced motor control. This cutting-edge control approach works with or without an encoder. Vector Control using FORCE Technology allows precise speed and position control with an encoder, improving industrial processes. Since it estimates motor characteristics without an encoder, it can perform well in applications where an encoder is impracticable or too expensive.
This drive also offers Sensorless Vector Control, which allows precise motor control without feedback. This control approach estimates motor speed and torque in real-time using advanced algorithms for best performance and energy efficiency. Sensorless Vector Control minimizes maintenance and system complexity by eliminating physical sensors, making it suited for many applications.
Additional Features:
The Allen-Bradley 20AD014A0AYNANC0 is distinguished by its Zero Stacking capability, which enables the drives to be mounted in close proximity without affecting the ambient temperature. This function optimizes the utilization of space in control interfaces.
The drive also includes an Internal Dynamic Brake Resistor, which eliminates the necessity for additional panel space and provides high braking torque for brief durations. This feature is essential for applications that require rapid deceleration.
The 20AD014A0AYNANC0s Integral EMC Filtering feature provides a compact solution to meet EMC requirements, thereby minimizing electromagnetic interference and ensuring compliance with industry standards. Furthermore, the Integral Dynamic Brake Transistor offers a cost-effective approach to switching regenerative energy, eliminating the necessity for costly external chopper circuits and thereby improving the drives operational efficacy.
The Flexible Fault Configuration is another critical feature of the Allen-Bradley 20AD014A0AYNANC0. This feature enables programmable adapters to execute specific actions in response to fault conditions. This feature improves the drives capacity to safeguard the system from potential damage and ensure continuous operation.
Frequently Asked Questions:
Does the 20AD014A0AYNANC0 require additional space for the dynamic brake resistor?
No, the 20AD014A0AYNANC0 is equipped with an internal dynamic brake resistor, which eliminates the necessity for additional panel space. For brief periods, this attribute generates substantial braking torque.
What control methods does the 20AD014A0AYNANC0 support?
The 20AD014A0AYNANC0 can support Vector Control with FORCE Technology, Sensorless Vector Control, and Volts per Hertz control. These techniques improve energy efficacy and motor control.
How does the 20AD014A0AYNANC0 handle fault conditions?
The 20AD014A0AYNANC0 has a Flexible Fault Configuration feature that allows programmable adapters to execute specific actions in response to fault conditions. This improves system protection and continuous operation.
Product Specifications Table:
| Attributes | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Output Voltage Range | 0-460 Volts AC |
| Output Current | 14 Amperes |
| Dual Output Power | 10 HP (Normal Duty), 7.5 HP (Heavy Duty) |
| Input Voltage Range | 380-480 VAC |
| Enclosure Rating | IP20/IP00 |
| Frame | C |
| Phases | 3 |
| Enclosure Type | Panel Mount |
| Control Methods | Vector Control w/FORCE Technology, Sensorless Vector, V/Hz |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
