Allen-Bradley 20AD014A3AYNANC0
Allen-Bradley 20AD014A3AYNANC0
The Allen-Bradley 20AD014A3AYNANC0 is an AC drive highly regarded Allen-Bradley PowerFlex 70 series member. It is renowned for its robustness and versatility as a variable frequency drive (VFD) expressly designed for industrial applications. This drive is notably recognized for its capacity to improve the performance and efficiency of motor-driven systems in a diverse array of industrial processes, rendering it an indispensable element in contemporary automation systems.
Technical Specifications:
The 20AD014A3AYNANC0 delivers a substantial output of 7.5 kW (10 hp) within its compact Frame C dimensions. It operates at an impressive 480V AC voltage and a current rating of 14 amps. With a weight of 6.89 kilograms and precise dimensions of 300.0 x 185.0 x 179.8 millimeters, this drive is housed in a durable Panel Mount configuration.
The interface is designed to be user-friendly, with a Full Numeric LCD module that enables exhaustive monitoring capabilities and seamless operation. This enables real-time adjustments and diagnostics to improve operational efficiency. Adhering to precise mounting guidelines is imperative to guarantee optimal performance and longevity. To effectively mitigate heat accumulation and protect against potential operational anomalies, it is essential to maintain a spacing of 76.2 millimeters both below and above the vertically mounted drive.
Additionally, the drive's operational reliability and integrity must be maintained by ensuring the installation environment is strictly controlled and free of corrosive gases and contaminants. The drive's exceptional efficiency is further emphasized by its modest total power dissipation, rated at a commendable 225.3 Watts.
Furthermore, the drive guarantees uninterrupted performance in rigorous industrial environments by maintaining unwavering stability in fluctuating power supply conditions, thanks to an input frequency tolerance of 47 Hz.
Communication Capabilities:
Although the drive lacks a built-in communication port, users can use various optional communication modules, such as DeviceNet, ControlNet, Ethernet, and serial modules. This broad range of communication options enables users to integrate the drive into various industrial networks and protocols, improving interoperability and adaptability to various operational environments. The 20AD014A3AYNANC0's utility is maximized across a wide range of industrial contexts due to its adaptability to satisfy the specific requirements of each application.
Safety Instructions:
Adhere to rigorous safety protocols when interacting with high-voltage equipment, such as the 20AD014A3AYNANC0 drive. To mitigate potential hazards and guarantee the safe and dependable operation of the drive in industrial environments, adhere to electrical codes and regulations and implement proper grounding procedures.
To mitigate risks and guarantee optimal operational safety, it is strongly recommended that users adhere to the exhaustive safety guidelines delineated in the product documentation. This involves complying with all recommended practices to prevent electrical shock, short circuits, and other potential hazards associated with high-voltage devices, as well as ensuring that all installation and maintenance activities are conducted by qualified personnel and using appropriate personal protective equipment.
Frequently Asked Questions:
What communication options are available for the 20AD014A3AYNANC0 drive?
The drive supports optional communication modules like Ethernet, ControlNet, and serial modules. These modules help seamlessly integrate various industrial networks and protocols.
What are the recommended mounting requirements for the 20AD014A3AYNANC0 drive?
A spacing of 76.2 millimeters should be maintained below and above the vertically mounted drive to guarantee optimal performance. Furthermore, ensure that the drive is installed in an environment devoid of corrosive gases and aerosols.
Is the 20AD014A3AYNANC0 drive suitable for outdoor installations?
No, this drive is housed in a NEMA Type 1 enclosure for interior use. Exposure to environmental elements during outdoor installations may jeopardize the drive's performance and longevity.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Voltage | 480V AC |
| Current | 14 amps |
| Power Output | 7.5 kW (10 hp) |
| Frame | C |
| Enclosure | Panel Mount |
| Interface Module | Full Numeric LCD |
| Communication Options | Optional communication modules |
| Weight | 6.89 kilograms |
| Dimensions | 300.0 x 185.0 x 179.8 mm |
| Power Dissipation | 225.3 Watts |
