Allen-Bradley 20AD022A0AYNANC0

The Allen-Bradley 20AD022A0AYNANC0 is a high-performance drive from the renowned PowerFlex 70 AC Drive series. This drive is a prime example of innovation and reliability, as it is engineered for optimal efficiency and seamless integration. This product is a testament to the quality and sophisticated engineering of Allen-Bradley, a trusted brand.

Technical Specifications:

The Allen-Bradley 20AD022A0AYNANC0 can operate across three phases and is equipped with a manual control type, making it suitable for various industrial environments. It optimizes energy usage, resulting in cost savings and environmental benefits, and boasts an impressive efficiency rating of 97.5% at rated amps.

The Allen-Bradley 20AD022A0AYNANC0 is a high-performance variable frequency drive specifically engineered for efficient operation and precise control in industrial applications. Its 15 HP power rating makes it easy to manage challenging duties.

The drive enables reliable operation in various industrial configurations by operating at 480V voltage and 22 Amps. It is enclosed within a panel-mount enclosure, guaranteeing seamless integration into control systems while maintaining a compact footprint.

Enhanced control capabilities, which are facilitated by 24V I/O, provide precise command over operational parameters, ensuring consistency and reliability in performance. This drive is engineered to be seamlessly integrated into control cabinets or enclosures, with a height of 350 mm, a depth of 210.7 mm, and a width of 219.9 mm. Its suitability for industrial applications is further enhanced by its ability to maintain a balance between durability and simplicity of installation despite weighing 9.13 kg.

Operating Environment:

The Allen-Bradley 20AD022A0AYNANC0 is designed to operate consistently in challenging environments. It can work in various climates and altitudes, with a temperature range of 32 to 122 °F and an altitude tolerance of up to 1000 m. Furthermore, a humidity range of 5% to 95% guarantees the ability to operate in various industrial settings.

Safety Features:

The Allen-Bradley 20AD022A0AYNANC0 is designed with safety features that prioritize the welfare of both personnel and equipment. The Flying Start feature facilitates a seamless connection with rotating loads without requiring a commanded direction and speed feedback device, thereby minimizing delay and guaranteeing operational continuity.

Additionally, the drives Inertia Ride-Through feature improves stability during abrupt load changes, facilitating uninterrupted operation. The droop control option optimizes performance in multi-drive configurations by providing precise regulation for load-sharing applications.

The Sleep/Wake Control option provides operational processes with additional flexibility by allowing for analog control of start and stop functions. Vector Control, which incorporates FORCE technology, guarantees precise control over motor performance by providing exceptional torque and speed regulation.

The Sensorless Vector Control feature enhances adaptability and performance across various applications by adjusting to suit specific motor characteristics.

Furthermore, the internal dynamic brake resistor generates a substantial amount of braking torque for brief periods, so there is no requirement for additional panel space, and the safety is improved. The Allen-Bradley 20AD022A0AYNANC0 prioritizes motor safety by providing motor overload protection, which protects against potential damage and extends the lifetime of the equipment.

Frequently Asked Questions:

What is the power rating and efficiency of the Allen-Bradley 20AD022A0AYNANC0?

The Allen-Bradley 20AD022A0AYNANC0 has a 15 HP power rating and an impressive efficiency rating of 97.5% at rated amps, optimizing energy usage.

What are the dimensions and weight of the Allen-Bradley 20AD022A0AYNANC0?

The drive measures 350 mm in height, 179.8 mm in depth, and 219.9 mm in width, weighing 9.25 kg for easy integration into control systems.

What voltage and amperage does the Allen-Bradley 20AD022A0AYNANC0 operate at?

The drive operates at 480V voltage and 22 Amps, ensuring reliable performance in various industrial configurations.
