Description

Allen-Bradley 20AD052A0AYNANC0

The Allen-Bradley 20AD052A0AYNANC0 is a high-performance Adjustable Frequency drive from the PowerFlex 70 series that is specifically engineered for general-purpose industrial applications. This drive is renowned for its robust features and exceptional performance, guaranteeing dependable operation and improved control in various environments.

Technical Specifications:

The Allen-Bradley 20AD052A0AYNANC0 drive is precisely engineered to offer a wide range of functions and high performance for demanding industrial applications. This drive weighs 18.60 kilos and measures 11.04 inches wide and 21.88 inches tall, making it sturdy but manageable for varied installation scenarios.

The 40-horsepower 20AD052A0AYNANC0 drive runs effectively with a 480-volt 3-phase voltage supply, making it ideal for many industrial applications that require high power and reliability. Despite not having an interface module, the drives conformal coating protects it from humidity, dust, and corrosive chemicals, extending its lifespan.

This drives manually operated control system uses an Insulated-Gate Bipolar Transistor (IGBT) for efficient brake control. IGBT technology ensures high-speed switching and minimal conduction losses, improving drive efficiency and performance. This drive also has dynamic brakes, which are crucial for rapid deceleration. However, this drive does not have a brake resistor, which may need to be purchased separately depending on the application.

The 20AD052A0AYNANC0 drive has a 24 Volt input and output voltage for better control. The drive also has advanced thermal management features to minimize overheating and assure smooth performance under severe loads. It has forced air and other cooling options to remove heat and optimize performance.

A digital keypad with an easy layout simplifies parameter adjustment and real-time monitoring on the drive. The drive also supports remote configuration and diagnostics software, facilitating maintenance and troubleshooting.

Mounting:

The Allen-Bradley 20AD052A0AYNANC0 drive must be mounted vertically without using standoffs or spacers. Its IP20, NEMA/UL Type 1 enclosure allows installation flexibility, as it can be affixed inside or outside a control cabinet. This durable enclosure protects the drive from dust and other contaminants, guaranteeing enduring performance.

Make sure the drives heatsink is adequately cooled, and that ventilation through the chassis is not obstructed during installation. The panel mounting methods practical design incorporates a vertically removable conduit plate, which enables effortless installation and replacement without disrupting the conduit. Furthermore, a 76.2 mm (3.0 inch) installation clearance is necessary for both the top and bottom spaces to guarantee adequate ventilation and heat dissipation.

Special Features:

Several sophisticated features are included in the 20AD052A0AYNANC0 drive to improve its functionality and user-friendliness. The flying start feature enables a seamless connection to rotating loads, reducing mechanical stress and delays. Furthermore, the drive is equipped with a PI control, eliminating the need for a distinct process loop controller that streamlines the systems design and decreases the overall cost.

In addition, this drive boasts user sets that facilitate effortless configuration and customization, as well as inertia ride-through, which ensures uninterrupted operation during brief power outages.

The slide compensation feature guarantees consistent speed control in fluctuating load conditions. This drive is also compatible with other Allen-Bradley DPI communication adapters, providing a variety of communication options.

Frequently Asked Questions:

What is the input voltage requirement for the Allen-Bradley 20AD052A0AYNANC0?

The Allen-Bradley 20AD052A0AYNANC0 requires a three-phase supply of 480 volts. This guarantees high-performance operation and sufficient power for its 40 horsepower rating.

What mounting options are available for the 20AD052A0AYNANC0?

The 20AD052A0AYNANC0 must be mounted vertically. It can be installed either inside or outside a control cabinet. Its NEMA/UL Type 1 enclosure, which is IP20-rated, ensures protection against environmental elements.

What is the weight of the Allen-Bradley 20AD052A0AYNANC0?

The 20AD052A0AYNANC0 weighs approximately 18.60 kilograms (41.0 pounds), which is manageable for most industrial mounting applications.

Product Specifications Table:

Attribute	Specification
Weight	18.60 kilograms (41.0 pounds)
Dimensions	11.04 inches (W) x 21.88 inches (H)
Input Voltage	480 Volts 3-phase
Power Rating	40 Horsepower
Drive-Mounted Brake Resistor	Not Available
Control Voltage	24 Volts input/output
Installation Clearance	76.2 mm (3.0 inches) top and bottom space
Control Options	Volts / Hertz, Sensorless Vector Control, Vector Control with FORCE Technology
Communication Compatibility	Allen-Bradley DPI communication adapters
Features	Flying start, PI control, inertia ride-through
