Allen-Bradley 20AD8P0A0AYNNNC0

The Allen-Bradley 20AD8P0A0AYNNNC0 is a high-performance variable frequency drive (VFD) component of the PowerFlex 70 series. It is engineered to offer energy efficiency and precise motor control for a diverse array of industrial applications. This drive is designed to provide dependable performance, sophisticated features, and durable construction, rendering it an excellent choice for demanding environments.

Technical Specifications:

The Allen-Bradley 20AD8P0A0AYNNNC0 VFD has an exceptional efficiency rating of 97.5% at rated amps, guaranteeing reduced operational costs and optimal energy usage. It is equipped with internal dynamic brake resistors rated at 115 Ohm, which improve the systems stability and the brakes efficacy. This drive is appropriate for high-power industrial applications because it operates at a main voltage of 480V. The voltage tolerance is established at -10%, ensuring consistent operation in fluctuating power conditions.

The 20AD8P0A0AYNNNC0 is engineered to operate in durable and reliable industrial environments. It is equipped with three-phase power, which enables it to manage higher power levels efficiently.

The drive supports a diverse range of motor sizes and types by delivering a current of 5 Amps. The drive can deliver 3 horsepower for normal-duty output and 2 horsepower for heavy-duty output, providing versatility in various application scenarios.

Moreover, it has an IP66 rating, which guarantees protection against dust and forceful water jets, making it suitable for harsh environments. Additionally, it offers a wall or machine mounting option.

The Allen-Bradley 20AD8P0A0AYNNNC0 has a conformal coating that safeguards the electronic components from temperature extremes, chemicals, moisture, and dust, thereby extending the drives lifecycle.

The drive provides effortless access to programming and control capabilities by including a comprehensive keypad interface. The braking capabilities of the drive are increased by incorporating a brake IGBT, which enables the motor to decelerate rapidly. Furthermore, this VFD has a second environment filter per the CE EMC directive 89/336/EEC, which guarantees adherence to rigorous electromagnetic compatibility standards.

Operating Parameters:

The Allen-Bradley 20AD8P0A0AYNNNC0 is engineered to operate in diverse environmental conditions. The drive can operate at altitudes of up to 3300 feet without derating, guaranteeing dependable performance in elevated locations. It is suitable for extreme temperatures, as it can endure storage temperatures as low as -40 °C. Additionally, the drive can operate in environments with a relative humidity of up to 95%, ensuring consistently reliable performance in humid environments.

Applications:

The drive is suitable for precise motor control and energy conservation situations due to its efficiency and robustness. This drive controls pump and fan speeds in HVAC, water treatment, and other fluid handling systems for optimal performance and energy savings. It is also best suited for the automotive, logistics, and industrial industries to control conveyor and hoist speed and torque, boosting system efficiency and dependability.

The drive also regulates compressors in industrial processes to save energy and maintain pressure. In the food and beverage, chemical, and pharmaceutical industries, mixers and agitators assure consistent blending and product quality with exact control.

Frequently Asked Questions:

Does the Allen-Bradley 20AD8P0A0AYNNNC0 support heavy-duty applications?

Yes, the Allen-Bradley 20AD8P0A0AYNNNC0 can support heavy-duty applications with a maximum output of 2 horsepower and a normal-duty output of 3 horsepower.

What is the main voltage and tolerance for the Allen-Bradley 20AD8P0A0AYNNNC0?

The Allen-Bradley 20AD8P0A0AYNNNC0 operates at 480V with a voltage tolerance of -10%. This enables the motor to function consistently in the presence of varying power conditions.

What mounting options are available for the Allen-Bradley 20AD8P0A0AYNNNC0?

The Allen-Bradley 20AD8P0A0AYNNNC0 can be mounted on a wall or machine and has an IP66 rating. This rating safeguards against dust and forceful water jets, making it appropriate for harsh environments.
