Allen-Bradley 20BD014A3AYNANC0

The Allen-Bradley 20BD014A3AYNANC0 is a highly reliable and versatile AC drive from the PowerFlex 700 series. It is engineered to accommodate a diverse array of industrial applications, offering advanced features, robust performance, and precise motor control to guarantee efficient and effective operation.

Technical Specifications:

The Allen-Bradley 20BD014A3AYNANC0 generated 59 dB in the Frame 1 enclosure, minimizing industrial noise. Due to its outstanding intermittent overload performance, this VFD can overload 110% for one minute and 150% for three seconds, making it highly resilient in demanding applications.

Internal EMC filtering and a common mode choke improve electromagnetic compatibility in the drive. This prevents EMI and maintains signal integrity in critical industrial situations.

With its 420 Hz output frequency, the VFD can control motor speed in a wide range of applications. Using digital inputs ensures precise and dependable performance with frequency accuracy within ±0.01% of the selected output frequency.

The motor operates consistently and reliably with the Allen-Bradley 20BD014A3AYNANC0s 14 A continuous output current. It works with 480V industrial power systems. The motor needs a 30 A fuse to prevent overcurrent. The VFD features two analog outputs for control and monitoring.

PWM at 4 kHz improves motor performance and lowers noise. This drives IP20 classification protects against solid items over 12mm but not liquids in indoor environments. The VFDs LCD user interface and full numeric keyboard make it easy to set up, monitor, and change.

The drive measures 336 mm high, 200 mm deep, and 135 mm wide. This compact design makes installation easier in various locations. Despite its strength, the 9.98-kg drive is easy to handle and install.

Installation:

This Allen-Bradley 20BD014A3AYNANC0 is intended for easy installation and integration into existing systems. It is designed to be readily mounted in control panels and is well-suited for tight spaces due to its compact form.

Comprehensive installation instructions are included with the drive to guarantee correct setup and operation. To preserve optimal performance, it is crucial to guarantee that the installation environment is devoid of excessive moisture and dust, as the IP20 rating renders it suitable for internal use.

Features:

The Allen-Bradley 20BD014A3AYNANC0 VFD includes advanced features, including droop control, which is necessary for the simultaneous control of multiple motors. The drive is designed to operate in grounded and ungrounded distribution systems and is equipped with removable MOV to-ground and common mode capacitors. This versatility renders it appropriate for a diverse array of industrial power configurations.

The drives interface is designed to be user-friendly, featuring a numeric keypad and display (LCD) that facilitates quick adjustments and monitoring by providing simple access to drive parameters and settings. The Allen-Bradley 20BD014A3AYNANC0 is an exceptional choice for demanding industrial applications due to its sophisticated features and robust design provide reliable and efficient motor control.

Frequently Asked Questions:

What is the maximum output frequency of the Allen-Bradley 20BD014A3AYNANC0?

The Allen-Bradley 20BD014A3AYNANC0 has a maximum output frequency of 420 Hz. This enables the control of motor speed to accommodate a wide variety of industrial applications.

What are the overload capabilities of the Allen-Bradley 20BD014A3AYNANC0?

For up to one minute, the 20BD014A3AYNANC0 is capable of 110% overload and 150% overload for up to three seconds. Even in the most challenging circumstances, these attributes guarantee consistent performances.

How does the Allen-Bradley 20BD014A3AYNANC0 handle EMC filtering?

The 20BD014A3AYNANC0 is equipped with internal EMC filtering and a common mode choke. This design reduces electromagnetic interference, preserving signal integrity in sensitive environments.
