Allen-Bradley 20BD022A3AYNANC0

Allen-Bradley 20Bd022A3Aynanc0

Allen-Bradley 20BD022A3AYNANC0

The Allen-Bradley 20BD022A3AYNANC0 is among the high-performance AC drives from the PowerFlex 700 series. This drive, designed for demanding industrial applications, has precise motor control, extensive features, and strong performance, making it excellent for many applications.

Technical Specifications:

The Allen-Bradley 20BD022A3AYNANC0's IP20 casing protects against solid objects larger than 12mm but not water. It can be installed in controlled conditions to prevent dust and physical contact. The AC DRIVE's LCD display shows operating conditions and parameters in real-time. Operators may input data and explore settings easily using the full numeric keypad.

With 22 amps output current, the drive performs well at 24V DC/AC I/O voltage. This allows a 15-horsepower motor, making it suited for medium-sized industrial applications. This AC DRIVE regulates speed by at least 0.5% throughout a wide speed range without speed feedback devices, ensuring motor performance.

TorqProve technology makes this AC DRIVE outstanding in transferring loads from the drive to external brake devices. Cranes and hoists need this technology for precise load handling and safety. Its size one frame makes the drive compact and easy to fit into existing control panels without requiring considerable space changes.

The Allen-Bradley 20BD022A3AYNANC0 also reduces electrical noise and meets industrial electromagnetic compatibility (EMC) standards with electromagnetic filtering. The drive also provides two independently programmable acceleration and deceleration times from 0 to 360 seconds. This versatility lets operators tailor the drive's reaction to application needs, improving process control and efficiency.

Droop control helps share the load across drive motors. This is useful for seamless motor integration in conveyor systems and multi-motor machines. The 60 Hz, three-phase drive offers continuous performance and compatibility with conventional industrial power supplies.<./p>

The Allen-Bradley 20BD022A3AYNANC0 may communicate with control systems and devices via RS485. This makes integration with automated systems easy, enabling extensive control and monitoring.

Advanced Control Features:

The drive provides exceptional speed and torque control for three-phase induction motors by supporting vector control with 24V DC I/O and guarantees precise control in a variety of applications, thereby improving the drive's overall efficiency and performance.

Additionally, the drive offers a variety of programmable stop modes, including ramp, coast, DC-brake, fast brake, ramp-to-hold, and S-curve, which enable the customization of halting mechanisms to accommodate varying operational requirements.

Robust Design and Efficiency:

The Allen-Bradley 20BD022A3AYNANC0 is engineered to function effectively in challenging environments. It guarantees minimal energy loss during operation, with a high efficiency of 97.5% at nominal line voltage and rated amps. Additionally, the drive is equipped with ground fault and overcurrent trip protections, which improve its reliability and safety.

Furthermore, the drive is guaranteed to comply with industrial standards for electromagnetic compatibility by incorporating an EMC filter and a common mode choke, which mitigates electrical noise and interference within the system.

Frequently Asked Questions:

What is the enclosure rating of the Allen-Bradley 20BD022A3AYNANC0?

The Allen-Bradley 20BD022A3AYNANC0 has an IP20 enclosure rating. This implies that it safeguards against substantial objects larger than 12mm, but it does not provide protection against water infiltration.

What communication capabilities does the Allen-Bradley 20BD022A3AYNANC0 offer?

The Allen-Bradley 20BD022A3AYNANC0 is equipped with RS485 communication capabilities. This enables it to communicate with various control systems and devices, allowing more complex monitoring and control.

How can the acceleration and deceleration times be programmed in the Allen-Bradley 20BD022A3AYNANC0?

The Allen-Bradley 20BD022A3AYNANC0 supports two independently programmable acceleration and deceleration periods, with a range of 0 to 360 seconds. These parameters can be adjusted to accommodate the specific needs of the application.

Product Specifications Table:

Attribute Specification
Enclosure IP20
Operator Interface LCD Display, Full Numeric Keypad
I/O Voltage 24V DC/AC
Output Current 22 Amps
Power 15 HP
Speed Regulation At least 0.5% without additional speed feedback
Technology TorqProve for load transfer
Frame Size Size 1
Electromagnetic Filtering Yes
Acceleration/Deceleration Time Programmable 0-360 seconds

Allen-Bradley 20BD022A3AYNANC0

Regular price
Sale price
$2,790.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
