Allen-Bradley 20BD065A3AYNANC0

Allen-Bradley 20Bd065A3Aynanc0

Allen-Bradley 20BD065A3AYNANC0

The Allen-Bradley 20BD065A3AYNANC0 is a high-performance AC drive in the PowerFlex 700 series. It is specifically engineered to deliver superior motor control and improved energy efficiency in industrial applications. This drive is appropriate for a variety of demanding environments, guaranteeing optimal performance and longevity. It is also robust and reliable.

Technical Specifications:

The Allen-Bradley 20BD065A3AYNANC0 is well-protected against dust and solid object ingress, as it has an IP20 rating. This drive provides precise control and seamless motor operation by operating at 650V DC with a Pulse Width Modulation (PWM) frequency of 4 kHz.

The 20BD065A3AYNANC0 is a compact yet powerful device that seamlessly fits into narrow spaces and delivers robust performance, with dimensions of 222 x 517.5 x 200 mm. This drive is relatively lightweight, weighing only 22.68 kg, which facilitates installation and maintenance in a variety of industrial configurations.

The drive is compatible with a wide range of industrial power systems. It operates at a mains voltage of 480 V. It is equipped with a logic control ride-thru capability, which guarantees uninterrupted operation during brief power interruptions. The ride-thru capability has a minimum duration of 0.5 seconds and a typical duration of 2 seconds.

This drive is suitable for environments where noise reduction is essential, as noise levels are maintained at a manageable 61 dB. The motor overload protection is classified as Class 10, which guarantees the longevity of the connected motor and provides dependable protection against overheating.

The 20BD065A3AYNANC0's efficiency and efficacy in power utilization are demonstrated by its total watts loss of 717 W. Furthermore, the drive comes with two analog outputs, which facilitate complex applications' monitoring and control capabilities.

Ambient Working Parameters:

The Allen-Bradley 20BD065A3AYNANC0 is engineered to function effectively in demanding environmental conditions. It is suitable for use in high-temperature industrial environments, as it can operate at an optimal temperature of up to 50 °C.

The drive also maintains consistent performance in environments with fluctuating humidity levels, operating reliably within a relative humidity range of 5% to 95%. This robustness renders it a flexible solution for various industrial applications, as it maintains its efficiency and reliability in various ambient conditions.

Additional Features:

The drive is equipped with a brake IGBT, significantly enhancing the braking system's efficacy and overall performance. Additionally, it incorporates a second environment filter that complies with the CE EMC directive (89/336/EEC), ensuring that it meets stringent electromagnetic compatibility standards and effectively mitigates electrical interference.

While the Allen-Bradley 20BD065A3AYNANC0 model has no internal brake resistor, it is designed with advanced vector control capabilities. These capabilities improve its performance and feature set, offering a marked advantage over conventional control models. It is important to note that this vector control does not support ScanPort, highlighting its specialized and unique configuration tailored for specific applications.

Frequently Asked Questions:

What are the dimensions of the Allen-Bradley 20BD065A3AYNANC0?

The 20BD065A3AYNANC0 measures 222 x 517.5 x 200 mm. These compact dimensions facilitate effortless integration into a variety of industrial configurations.

What is the operating temperature range for the Allen-Bradley 20BD065A3AYNANC0?

The 20BD065A3AYNANC0 is suitable for high-temperature industrial environments due to its ability to operate at temperatures as high as 50 °C.

Does the Allen-Bradley 20BD065A3AYNANC0 include motor overload protection?

Indeed, it does, and it is classified as Class 10. This safeguard serves to prevent motor overloading and extends the motor's lifespan.

Product Specifications Table:

Attribute Specification
Degree of Protection (IP) IP20
PWM Frequency 4 kHz @ 650V DC
Dimensions (W x H x D) 222 x 517.5 x 200 mm
Weight 22.68 kg
Mains Voltage 480 V
Logic Control Ride-Thru 0.5 seconds minimum, 2 seconds typical
Noise Level 61 dB
Motor Overload Protection Class 10
Total Watts Loss 717 W
Operating Temperature 0 to 50 degree centigrade

Allen-Bradley 20BD065A3AYNANC0

Regular price
$5,990.00
Sale price
$5,990.00
We currently have 3 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley 20BD065A3AYNANC0

The Allen-Bradley 20BD065A3AYNANC0 is a high-performance AC drive in the PowerFlex 700 series. It is specifically engineered to deliver superior motor control and improved energy efficiency in industrial applications. This drive is appropriate for a variety of demanding environments, guaranteeing optimal performance and longevity. It is also robust and reliable.

Technical Specifications:

The Allen-Bradley 20BD065A3AYNANC0 is well-protected against dust and solid object ingress, as it has an IP20 rating. This drive provides precise control and seamless motor operation by operating at 650V DC with a Pulse Width Modulation (PWM) frequency of 4 kHz.

The 20BD065A3AYNANC0 is a compact yet powerful device that seamlessly fits into narrow spaces and delivers robust performance, with dimensions of 222 x 517.5 x 200 mm. This drive is relatively lightweight, weighing only 22.68 kg, which facilitates installation and maintenance in a variety of industrial configurations.

The drive is compatible with a wide range of industrial power systems. It operates at a mains voltage of 480 V. It is equipped with a logic control ride-thru capability, which guarantees uninterrupted operation during brief power interruptions. The ride-thru capability has a minimum duration of 0.5 seconds and a typical duration of 2 seconds.

This drive is suitable for environments where noise reduction is essential, as noise levels are maintained at a manageable 61 dB. The motor overload protection is classified as Class 10, which guarantees the longevity of the connected motor and provides dependable protection against overheating.

The 20BD065A3AYNANC0's efficiency and efficacy in power utilization are demonstrated by its total watts loss of 717 W. Furthermore, the drive comes with two analog outputs, which facilitate complex applications' monitoring and control capabilities.

Ambient Working Parameters:

The Allen-Bradley 20BD065A3AYNANC0 is engineered to function effectively in demanding environmental conditions. It is suitable for use in high-temperature industrial environments, as it can operate at an optimal temperature of up to 50 °C.

The drive also maintains consistent performance in environments with fluctuating humidity levels, operating reliably within a relative humidity range of 5% to 95%. This robustness renders it a flexible solution for various industrial applications, as it maintains its efficiency and reliability in various ambient conditions.

Additional Features:

The drive is equipped with a brake IGBT, significantly enhancing the braking system's efficacy and overall performance. Additionally, it incorporates a second environment filter that complies with the CE EMC directive (89/336/EEC), ensuring that it meets stringent electromagnetic compatibility standards and effectively mitigates electrical interference.

While the Allen-Bradley 20BD065A3AYNANC0 model has no internal brake resistor, it is designed with advanced vector control capabilities. These capabilities improve its performance and feature set, offering a marked advantage over conventional control models. It is important to note that this vector control does not support ScanPort, highlighting its specialized and unique configuration tailored for specific applications.

Frequently Asked Questions:

What are the dimensions of the Allen-Bradley 20BD065A3AYNANC0?

The 20BD065A3AYNANC0 measures 222 x 517.5 x 200 mm. These compact dimensions facilitate effortless integration into a variety of industrial configurations.

What is the operating temperature range for the Allen-Bradley 20BD065A3AYNANC0?

The 20BD065A3AYNANC0 is suitable for high-temperature industrial environments due to its ability to operate at temperatures as high as 50 °C.

Does the Allen-Bradley 20BD065A3AYNANC0 include motor overload protection?

Indeed, it does, and it is classified as Class 10. This safeguard serves to prevent motor overloading and extends the motor's lifespan.

Product Specifications Table:

Attribute Specification
Degree of Protection (IP) IP20
PWM Frequency 4 kHz @ 650V DC
Dimensions (W x H x D) 222 x 517.5 x 200 mm
Weight 22.68 kg
Mains Voltage 480 V
Logic Control Ride-Thru 0.5 seconds minimum, 2 seconds typical
Noise Level 61 dB
Motor Overload Protection Class 10
Total Watts Loss 717 W
Operating Temperature 0 to 50 degree centigrade

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 20BD065A3AYNANC0-R $5,990.00 USD 2 Year Extended Warranty 3 In Stock in the U.S.A!
