Description

Allen-Bradley 20F1AND125AA0NNNNN

The Allen-Bradley 20F1AND125AA0NNNNN AC Drive is a robust and efficient device designed for industrial motor control applications. This AC drive is part of the PowerFlex 753 series. This drive has an enclosure rating of IP20/IP00. It is a NEMA/UL Type Open rated enclosure. It includes internal AC filtering. It does not have a door-mounted Human Interface Module (HIM). It comes with Frame 6 hardware.

Technical Description:

The Allen-Bradley 20F1AND125AA0NNNNN operates with an input type of AC with precharge, ensuring a stable and reliable power supply. It supports a continuous output current of 125 amperes in normal duty (ND) mode and 96 amperes in heavy duty (HD) mode.

The continuous output power in ND mode is 100 HP, while in HD mode it is 75 HP. This drive features dynamic braking through a DB transistor. With dimensions of 26.20 x 12.13 x 13.64 inches and a weight of 85 lbs, it is compact and manageable for various installations.

The voltage class for this drive is 480 AC volts, making it suitable for high-power applications. It belongs to frame size 6, which indicates its structural design and capacity. The 20F1AND125AA0NNNNN AC drive is equipped with several features to ensure optimal performance.

It has internal transistors and DC filtering, which contribute to efficient and smooth operation. This drive does not include an internal resistor.

Mounting and Safety Specifications:

The Allen-Bradley 20F1AND125AA0NNNNN supports premier integration, enhancing its compatibility with other automation systems. It is panel mounted, which simplifies installation and maintenance. The human interface module (HIM) is not included but can be added as per user requirements to provide an intuitive interface for monitoring and adjustments.

This drive is equipped with inherent safety functionalities, including support for hardwired Safe-Torque Off (STO) features. It complies with Safety Integrated Level (SIL3) Performance Level (PL e), CAT 3, and has an optional hardwired Safe Speed Monitor. These safety features are standard, ensuring the drive is capable of predictive diagnostics and adjustable voltage control.

Standard Operating Precautions:

When operating the Allen-Bradley 20F1AND125AA0NNNNN AC drive, it is essential to follow standard safety precautions to ensure reliable and safe performance. Ensure that the drive is installed in a suitable environment that meets the enclosure requirements. Regularly check and maintain the connections and components to prevent potential issues. The model must be operated by a trained professional to ensure maximum performance and prevent any damage.

Frequently Asked Questions:

What voltage class does the Allen-Bradley 20F1AND125AA0NNNNN AC Drive support?

This drive supports a voltage class of 480 AC volts. It is designed for high-power industrial applications. This makes it suitable for environments requiring substantial electrical input.

What are the dimensions and weight of the Allen-Bradley 20F1AND125AA0NNNNN AC Drive?

The dimensions of the drive are 26.20 x 12.13 x 13.64 inches. It weighs 85 lbs. These specifications ensure it is compact enough for various installations while providing sufficient power.

Does the Allen-Bradley 20F1AND125AA0NNNNN AC Drive support dynamic braking?

Yes, the drive supports dynamic braking. It utilizes a DB transistor to enhance motor control. This feature improves safety and operational efficiency by providing rapid stopping capabilities.

Product Specifications Table

Attribute	Specifications
Series	PowerFlex 753
Product Type	AC Drive
Continuous Output Current, ND	125 Amperes
Continuous Output Current, HD	96 Amperes
Continuous Output Power, ND	100 HP
Continuous Output Power, HD	75 HP
Input Type	AC Input with Precharge
Dynamic Braking	DB Transistor
Dimensions	26.20 x 12.13 x 13.64 inches
Weight	85 lbs
