Allen-Bradley 20G1AND156AA0NNNNN
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.
- 20G1AND156AA0NNNNN
- AC DRIVE
- AIR COOLED
- POWERFLEX 755
- AC INPUT WITH PRECHARGE
- IP20/IP00
- OPEN TYPE
- 480 VAC / 650 VDC
- 90 KW / 125 HP
- 156 AMP
- FILTERING
- JUMPER REMOVED
- INTERNAL TRANSISTOR
- NO HIM
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 20G1AND156AA0NNNNN
| Series | PowerFlex 755 |
|---|---|
| Part Number/Catalog No. | 20G1AND156AA0NNNNN |
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Default CM Cap Connection | Jumper removed |
| Internal Resistor | No |
| Internal Transistor | Yes |
| Control Method | V/Hz control, vector control with FORCE® technology, sensorless vector control, and permanent magnet motor control |
| Frame | 6 |
| Communication | Ethernet I/P |
| Voltage Rating | 480V AC, 3-Phase |
| Continuous Output Current, ND | 156 Amperes |
| Continuous Output Power, ND | 100 HP |
| Continuous Output Current, HD | 125 Amperes |
| Human Interface Module (HIM) | Not Included |
| Frames | 6...8 |
| Enclosure Type | AC Input with Precharge, no DC Terminals |
| Frames 2 | 2...7 |
| Enclosure Type 2 | IP20/IP00, NEMA/UL Type Open |
| Voltage | 480 Volts AC/650 Volts DC |
| Filtering | Yes |
