Allen-Bradley 2198-D057-ERS3
Allen-Bradley 2198-D057-ERS3
The Allen-Bradley 2198-D057-ERS3 servo drive represents a pinnacle of precision and performance in industrial automation. This advanced drive is designed to meet the demanding requirements of modern motion control systems. Its robust construction and state-of-the-art technology ensure unparalleled accuracy and reliability in applications ranging from robotics to material handling.
Technical Specifications:
The Allen-Bradley 2198-D057-ERS3 is a dual-axis regulator engineered to deliver consistent performance across various industrial applications. Operating at 240V input, it provides a continuous output power of 8.0 kW and scales up to 15.9 kW at 480V input. With an output current range of 23A to 57A, the Allen-Bradley 2198-D057-ERS3 boasts an output power rating of 15.6 kW at 324-528V AC RMS (three-phase), complemented by a DC input current of 24.5A at 458-747V DC. These specifications make it suitable for demanding applications requiring precise control and high power efficiency.
Designed to operate in ambient temperatures ranging from 0 to 50 degrees Celsius and humidity levels of 5-95% non-condensing, the servo drive can also be stored in temperatures spanning -40 to 70 degrees Celsius. Furthermore, the servo drive is engineered for installation at elevations of up to 1500 meters, making it suitable for deployment in various industrial environments globally. Its robust design and comprehensive specifications ensure reliability and efficiency, making it a preferred choice for a wide range of applications across industries.
Communication and Operation Features:
A standout feature of the Allen-Bradley 2198-D057-ERS3 is its seamless integration with the Logix controller platform. This integration facilitates direct communication and exchange of servo parameters between the drive and the Logix controller, simplifying setup and ensuring a synchronized control system. Furthermore, the drives connectivity extends to Human Machine Interface (HMI) and Supervisory Control and Data Acquisition (SCADA) systems. This integration allows for comprehensive monitoring and control of the servo drive through intuitive interfaces, empowering operators to oversee and optimize performance in real time.
In addition to its robust communication capabilities, the servo drive is designed to enhance user experience and streamline integration into industrial systems. Its compatibility with the Logix controller platform ensures that servo parameters can be effortlessly managed and monitored.
Safety Precautions:
When installing the Allen-Bradley 2198-D057-ERS3, it is essential to engage qualified personnel familiar with electrical systems and servo drive technology. Installation must comply with local electrical codes and safety regulations to ensure proper setup and operation. To maintain optimal performance and prevent overheating, ensure adequate airflow around the servo drive. Keep cooling fans and vents unobstructed to facilitate proper ventilation. Operating the drive in well-ventilated conditions extends its lifespan and reduces the risk of malfunctions.
Regularly monitor the Allen-Bradley 2198-D057-ERS3 for any unusual sounds, vibrations, or visual indicators. Promptly investigate and address any abnormalities to prevent potential hazards and system failures.
Frequently Asked Questions:
What is the output current capability of the Allen-Bradley 2198-D057-ERS3?
The Allen-Bradley 2198-D057-ERS3 boasts a continuous output current of 32.5A, which can handle peaks up to 81.3A. This ensures robust performance and reliable operation even under varying load conditions in industrial applications.
What are the physical dimensions and weight of the Allen-Bradley 2198-D057-ERS3?
Its compact dimensions of 9.92 x 3.35 x 17.0 inches and weight of 6.76 kg contribute to ease of installation and reduced wiring complexity, lowering overall installation costs.
What is the capacitance specification of the Allen-Bradley 2198-D057-ERS3?
A capacitance of 705 uF supports the Allen-Bradley 2198-D057-ERS3. This specification ensures stable operation and efficient performance in controlling and filtering electrical currents within industrial applications.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Kinetix 5700 |
| Input/Output Capacity | Input:2 digital, 1 encoder feedback. Output: 1 digital, 1 encoder |
| Voltage | 480 VAC |
| Dimensions | 9.92 x 2.17 x 14.09 inches |
| Communication Interface | Ethernet/IP |
| Compatibility | CompactLogix, DriveLogix, SoftLogix |
| Operating Temperature Range | 0 to 55 °C |
| Weight | 6.76 kg |
| Peak current | 81.3 A |
| Product Status | Active |
