Allen-Bradley 2198-H025-ERS2

Allen-Bradley 2198-H025-ERS2
Allen-Bradley 2198-H025-ERS2

Allen-Bradley 2198-H025-ERS2

$0.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley Kinetix 5500 Ethernet I/P servo drive, catalog number 2198-H025-ERS2, is engineered with dual compatibility for input supply voltage ranges of 195-264V rms and 324-528V rms, supporting both 240VAC and 480VAC nominal voltages. It delivers a continuous output current of 8.0 A and a peak current capacity of up to 28.3 A, with output power of 2.4 kW at lower voltage supply and 5.1 kW at higher voltage. Compact with dimensions of 225 mm in height, 55 mm in width, and 226 mm in depth, this frame 2 drive supports operating temperatures from 0°C to 50°C with the appropriate connector kit. Certified by cULus, CE, and more, it is protected by an IP20 rating and supports communication with Compact GuardLogix 5570 controllers via Ethernet/IP, allowing for safe power-off actions and various safety modes. Easy to install and highly adaptable, it supports bus-sharing multi-axis and standalone configurations, with options for additional capacitance through Bulletin 2097 external shunt resistors and Bulletin 2198 capacitor modules.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 2198-H025-ERS2 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Technical specifications for 2198-H025-ERS2

Manufacturer Rockwell Automation
Input Voltage 195…264V rms, three-phase (240V nom); 324…528V rms, three-phase (480V nom);
Continuous Output Current (0-peak) 5.0 A
Part Number/Catalog No. 2198-H025-ERS2
Brand Allen-Bradley
Product Category Kinetix 5500
Main AC input Current 5.20 A @ 240 V; 3.40 A @ 480V
Input Frequency: 47…63 Hz
Continuous Output Power 1.5 KW at 195…264V rms, three-phase; 3.2 kW at 324…528V rms, three-phase;
Continuous Output Current (rms) 7.1 A
Peak Output Current (0-peak) 12.5 A
Peak Output Current (rms) 17.7 A
Velocity Loop 300 Hz
Current Loop 1000 Hz
Efficiency 97%
Short-circuit current rating 200,000 A (rms) symmetrical
Integrated Safety Over Ethernet I/P Supported
Internal shunt power 50 W
Hardwired Safety No
Frame Size Frame Size 2
Peak Output Current 20 Amperes
Nom Drive Voltage 240/480 V (Three Phase)
Integrated Safety Over Ethernet/IP Yes
Dimensions 2.16 x 8.90 x 10.43 in (55 x 226 x 265 mm)
Weight 5.0 lbs (2.3 kg)
UPC 885630902746
