The Allen-Bradley 2198-H040-ERS is one of the renowned servo drives from Kinetix 5500. The company is well-known for its production of industrial automation components and equipment. It offers high efficiency and is suitable for fulfilling several user requirements. This servo drive includes many certifications and is specifically designed for accurate motion management in many engineering and industrial technologies application areas.
Technical Specifications :
This drive 2198-H040-ER is a three-phase servo drive capable of giving 4kW to 8.3kW continuous output power, having input voltage from 190-528 rms and 18.4A of continuous output current (0-pk).
This servo drive has an AC input frequency of 47 to 63Hz and contains 60 ohms of internal shunt resistance. The internal shunt power for the Allen-Bradley 2198-H040-ERS servo drive has been rated at 50W, which helps control a lot of energy generation during deceleration. It is discovered as a space saver with its compact design factor for easy integration into many systems.
It has 0.8 A DC for a 24V Current with a non-brake motor. This value varies for a 2A brake motor and becomes 2.8A DC. It weighs about 2.3 Kg, equivalent to 5.0 lb. The maximum cable length for the Kinetix 5500 drive depends upon various factors, including the specific drive and motor combination and the motor and cable combination. The Allen-Bradley 2198-H040-ERS keeps a peak current output of 32.5A, and its compact design and specifications have made this model fit for use in improving the precision and speed of many robotic arms.
Operational and Installation Parameters:
For installation of Allen-Bradley 2198-H040-ERS, it should be kept in mind that it operates at 0 to 50 °C (32 to 122 °F) ambient temperature. Furthermore, the relative humidity for this drive as a non-condensing atmosphere is given as 5 to 95 %. It requires panel mounting under high ventilation in a clean environment. The recommended minimum cabinet depth for installation is 300 mm (11.81 in.).Moreover, it is important to ensure additional clearance for cables, wires, or the shared-bus connection system attached to the top of the drive.
Safety Precautions:
For Allen-Bradley 2198-H040-ERS servo drive, ensure installation complies with parameters regarding wire types, conductor sizes, branch circuit protection, and disconnect devices. Turn off all power supplies and check connections to make the drive operate properly. Another paramount feature required for safety is ground-shielded power cables, which help to protect against potentially high voltages. Moreover, it is also important to note that hands shouldn't be wet before turning on the power supply; otherwise, it may lead to electrical shock and further damage.
Frequently Asked Questions:
Q1: What is the input power requirement for the 2198-H040-ERS?
A: The Allen-Bradley 2198-H040-ERS is a three-phase servo drive with input power of 190-528V AC to operate correctly under required specifications.
Q2.What protection against overload does the drive use?
This servo drive Allen-Bradley 2198-H040-ERS uses solid-state motor overload protection that operates concerning the requirements of UL that predict actual motor temperature based on operating conditions.
What is the purpose of safe-torque feature in 2198-H040-ERS?
The safe-torque aims to provide a method that turns off power transistor control signals, ensuring the drive will not produce torque on the motor.
