Allen-Bradley 2198-H070-ERS2

Allen-Bradley 2198-H070-ERS2
Allen-Bradley 2198-H070-ERS2

Allen-Bradley 2198-H070-ERS2

$0.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 2198-H070-ERS2 Kinetix 5500 Servo Drive is engineered for efficient system integration and future scalability, featuring dual Ethernet ports for linear and Device Level Ring (DLR) topologies. This drive supports direct integration with the Logix Programmable Automation Controller platform, enabling seamless operation with CompactLogix, ControlLogix, and GuardLogix controllers. It operates on a 3-phase input voltage of 190-528V AC and offers robust output capabilities with continuous and peak outputs of 23.0 A and 81.3 A, respectively, while delivering a continuous output power of 7.2 kW at 230 Vrms and 14.9 kW at 480 Vrms. Designed for high efficiency, this servo drive includes advanced safety features, such as short-circuit current detection and voltage protection, ensuring reliable and secure performance.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 2198-H070-ERS2 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Technical specifications for 2198-H070-ERS2

Manufacturer Rockwell Automation
Brand Allen-Bradley
Product Category Kinetix 5500
Part Number/Catalog No 2198-H070-ERS2
Control input voltage 24 VDC
Continuous Output current to bus 22.5 A
Continuous Output power to bus 7.2 kW @ 230 VAC; 14.9 kW @ 480 VAC
Continuous output current to motor 23.0 A
Peak output current to motor 57.5 A
Continuous output power 7.0 kW @ 195-264 VAC, 3-phase; 14.6 kW @ 324-528 VAC, 3-phase
Premiere Integration Supported
Compatible controllers CompactLogix, ControlLogix, GuardLogix
PWM Frequency 4 kHz
Hardwired Safety No
Frame Size Frame Size 3
Input Voltage 195…264V rms, three-phase (240V nom); 324…528V rms, three-phase (480V nom)
Peak Output Current 57.5 Amperes
Continuous Output Current (0-peak) 32.5 Amperes
Nom Drive Voltage 240/480 V (Three Phase)
Part Number/Catalog No. 2198-H070-ERS2
Integrated Safety Over Ethernet/IP Yes
Dimensions 3.35 x 8.90 x 11.57 in (85.2 x 226 x 294 mm)
Weight 9.0 lbs (4.1 kg)
Velocity loop bandwidth 300 Hz
Current loop bandwidth 1000 Hz
