Allen-Bradley 2198-S086-ERS4

The Allen-Bradley 2198-S086-ERS4 is a single-axis inverter manufactured by Rockwell Automation in the Kinetix 5700 drive series. It is designed with advanced safety features for precise motor control in demanding industrial environments. This inverter provides strong electrical performance, long-lasting construction, and a wide working range, providing reliable and efficient operation.

Electrical Specifications:

The 2198-S086-ERS4 inverter module consumes a DC input current of 45.7 A at 276 to 747 V DC and delivers a peak output current of 121.6 A (zero to peak). The DC input current and wide voltage range provide installation flexibility. The internal capacitance of the inverter is 560 µF and generates a rated power output of 475 W at 100%. The internal capacitance supports stable operation under varying load conditions.

The bandwidth of this inverter module is 400 Hz at the maximum velocity loop with a PWM frequency of 4 kHz. The high bandwidth at the velocity loop ensures rapid response, and high PWM frequency contributes to smoother operation. The invertor utilizes a control power current of 9.6 A at 24 V DC (maximum with maximum brake current) and generates a continuous power output of 29.7 kW at 480 V rms, 3-phase. The continuous power output at three-phase voltage enables strong performance.

Operational Parameters and Advanced Safety:

The 2198-S086-ERS4 inverter module weighs 5.21 kg and measures 433 mm height, 252 mm depth and 85 mm width. This servo drive inverter module can operate safely from -40 to 50 °C. The inverter can tolerate 2 G of vibration at peak continuous accelerations ranging from 55 to 500Hz. The S086-ERS4 inverter can endure a shock of 15 G with an 11 ms half-sine pulse. The non-operational storage altitude range is 3000 m (9843 ft) during shipping.

The inverter module functions securely thanks to its high degree of protection under the IEC 60529 safety standard. Similarly, the inverter has IEC 61800-5-1 safety for variable-speed electrical power drive systems that address electrical, thermal, and energy safety. The relative humidity for working and storage conditions ranges from 5% to 95% noncondensing.

Application and Performance:

The Allen-Bradley 2198-S086-ERS4 is built for severe industrial applications with advanced safety. Its intricate multi-axis control systems make it suitable for the manufacturing, automotive, and textile sectors. Its high continuous and peak output currents allow for accurate motor control. The control power current standard provides proper brake functioning.

The 2198-S086-ERS4 single-axis inverter has mounting tabs, a cutout for easy installation, and cooling fans to help control temperature. The products durability is increased by its vibration and shock resistance. The compact size and reasonable weight make installation simple. This single-axis inverter with advanced features is a reliable option for accurate motor control in industrial situations.

Frequently Asked Questions:

Does the Allen-Bradley 2198-S086-ERS4 support regenerative braking?

Yes, this inverter module supports regenerative braking. This function improves energy efficiency by returning energy to the power source during deceleration.

What type of communication interfaces does the 2198-S086-ERS4 support?

The single-axis inverter incorporates Ethernet/IP and CIP Safety to ensure easy integration and communication across industrial networks.

Does the 2198-S086-ERS4 have built-in EMC filtering?

Yes, the Allen-Bradley 2198-S086-ERS4 has built-in EMC filtering to reduce electromagnetic interference and ensure consistent performance in industrial situations.

Product Specifications Table

Attribute	Specifications
Continuous Output Current	43A
Peak Output Current	86A
Continuous Power Output	29.7kW
Pulse Width Modulation (PWM) Frequency	4000Hz
Rated Power Output	475 W
Control Power Current	9.6A
Internal Capacitance	560?F td>
Vibration Resistance	2 G at 55 to 500 Hz
Storage Altitude Range	3000 m (9843 ft)
Weight	5.21kg (11.5lb)
