Allen-Bradley 22A-B4P5N104
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 22AB4P5N104
- AC DRIVE
- ADJUSTABLE FREQUENCY
- POWERFLEX 4
- 240 VAC
- 3 PHASE
- 4.5 AMP
- 0.75 KW / 1 HP
- PANEL MOUNT - IP 20 NEMA TYPE OPEN
- FIXED KEYPAD
- NOT FILTERED
- STANDARD BRAKE
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 22A-B4P5N104
| Filter | Without CE Compliant Filter |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer: | |
| Input Voltage: | 240VAC |
| Rated Current output: | 4.5 A |
| Rated Power: | 0.75kW (1.0 HP) |
| Installation: | Panel Mount / DIN Rail |
| Enclosure Rating: | IP20 / NEMA UL Type Open |
| Keypad: | LED Keypad |
| Built-in Communication port: | RS485 |
| I/O Terminal: | Discrete Inputs: 3 fixed for START/STOP/REV; 2 Fully Programmble Discrete Outputs: 4 fully programmable; Analog Input: 2 1 0…10V or 4…20 mA) Discrete Output: 1 - N.O/N.C. dry contact; |
| Part Number/Catalog No. | 22A-B4P5N104 |
| Product Line | PowerFlex 4 |
| Amperage | 4.5 Amps |
| Enclosure Type | IP20/UL (Open) |
| Phase | 3-Phase |
| Wattage | 0.75 Kilowatt |
| Input Type | Keypad |
| Display | Light-Emitting Diode (LED) |
| Horsepower | 1 Horsepower |
| Input Power | 200 to 240 Volts AC |
| Brake Drive | Brake Drive |
| UPC | 662453979595 |
