Allen-Bradley 22C-B049A103
Allen-Bradley 22C-B049A103
The Allen-Bradley 22C-B049A103 is a famous Variable frequency drive from the PowerFlex 400 Series, known for its efficiency and performance in the field. It is specially designed to control three-phase induction motors, which is why it has versatile applications in the industry. p>
Technical Specifications:
The Allen-Bradley 22C-B049A103 drive works on the frequency range of 0 - 400 Hz. This high-frequency aids in controlling the speed of rotary equipment in the industry. It works on the principle of Sensorless vector control, which means it can work independently without the need for a feedback device.
The drive is enclosed in a NEMA/UL Type 1 case. The NEMA/UL case has strength and increased durability to perform in harsh environments. The drive operates at a voltage range of 480 V and a maximum horsepower of 15 Hp, making it more demanding in the industry. It can be integrated with multiple communication modules as it is compatible with different communication modules.
The Allen-Bradley 22C-B049A103 can be tailored to work with different operations as it is programmable easily. There are multiple inputs and outputs, such as Analogue, Digital, and communication module ports. It can control various parameters as well, like torque, Speed, and others.
Applications and Benefits:
The versatility of Allen-Bradley 22C-B049A103 makes it a must-have for multiple applications across the industry. It is well-reputed in the field of HVAC as it is considered very energy efficient in such applications. Maintenance of the drive is easy as technical assistance is provided.
The drives ability to control speed efficiently increases the system lifespan by reducing friction and other losses. With the help of real-time data exchange and advanced control features, the 22C-B049A103 helps improve operational efficiency and productivity.
The drive has a lot of other applications in pumping systems, conveyor systems, Industrial fans, blowers, and agitators. Its overall benefits include energy efficiency, enhanced performance, flexibility, and customization.
Advanced Control and Integration:
The Allen-Bradley 22C-B049A103 is complemented because it can be integrated into any type of existing system without any significant changes. The drive supports multiple communication modules which help it stand out then other drives. It can meet the special operational needs in the industry because users can change their parameters according to the requirements.
The Allen-Bradley 22C-B049A103 uses a total of 7 input signals to start stop and drive the motor. 0-10v DC signals are used to control the motor speed. The drive allows real-time data exchange for diagnostic and other calibrations.
The built-in protection includes abnormal voltage, short circuit, and overload protection which is another advanced control feature of the drive. Other advanced features are dynamic torque adjustment, precision motor regulation, and adaptive programming for optimized performance in diverse industrial applications
Frequently Asked Questions:
What is the maximum output current for the Allen-Bradley 22C-B049A103?
The Allen-Bradley 22C-B049A103 has a maximum output current of 49A. High current controls high load efficiently.
Can the 22C-B049A103 be integrated with a SCADA system?
Yes, the 22C-B049A103 supports communication protocols like DeviceNet and EtherNet/IP, enabling seamless integration with SCADA systems for advanced monitoring and control.
What type of motor control does the 22C-B049A103 use?
The Allen-Bradley 22C-B049A103 utilizes sensorless vector control technology, providing precise speed and torque regulation without the need for external feedback devices.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Output Voltage | 0 - 230 V AC |
| Maximum Output Current | 49A |
| Horsepower | 15 HP |
| Frequency Range | 0-400 Hz |
| Control Type | Sensorless Vector Control |
| Enclosure Type | NEMA/UL Type 1 |
| Digital Inputs | Up to 7 |
| Analog Inputs | 2 (0-10V DC or 4-20mA ) |
| Communication Protocols | DeviceNet, EtherNet/IP, Modbus |
| Input Current | 51 A |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
