Allen-Bradley 22C-D030N103

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.

22CD030N103
AC DRIVE
ADJUSTABLE FREQUENCY
POWERFLEX 400
480 VAC
3 PHASE
30 AMP
15 KW
20 HP
PANEL MOUNT - IP 20 NEMA TYPE OPEN
FIXED KEYPAD
NOT FILTERED
RS485

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition	SKU	Price	Warranty	Availability	Quantity	Purchase
Surplus Original Box	22C-D030N103-FS		2 Year Extended Warranty	Call for Availability		Call for Availability (877)-727-8757
IAC Certified Refurbished	22C-D030N103-R		2 Year Extended Warranty	Call for Availability		Call for Availability (877)-727-8757

Technical specifications for 22C-D030N103

Manufacturer	Rockwell Automation
Output Current	30.0 A @ 45 Deg. C and 27. 0 A @ 50 Deg. C
Input Voltage	380-480VAC
Part Number/Catalog No.	22C-D030N103
Brand	Allen-Bradley
Product Family:	PowerFlex 400 for Fan and Pump applications
Input Current:	31.0 A
Output Voltage:	0-460VAC
Output Power:	15.0 kW (20.0 HP)
I/O:	Discrete Inputs: Seven (7) Sink / Source Discrete Outputs: One (1) Open Output; Two (2) Form C Contacts Analog Input: Two (2) Analog Input 0-10VDC; 0- 20mA Analog Output: Two (2) Analog Input 0-10VDC; 0- 20mA
Enclosure Rating:	IP20 / NEMA UL Open Type
Control Method:	Sinusoidal PWM; Volts / Hertz
Built-in communication port:	RS485
Optional communication protocols:	BacNet; LonWorks; ProfiBus; Ethernet; DeviceNet; ControlNet
Product Line	Powerflex 400
Drive Type	Fan and Pump
Horsepower	20
Phase	3-Phase
Enclosure	Panel Mount - IP20, NEMA/UL Type Open
Frame Size	C
Dimensions	10.2 x 5.1 x 7.1 inches
Storage Temperature	-40 to 85 degrees Celsius
Frequency	50 to 60 Hertz
Control Type	RS-485
Mounting	Panel Mount
UPC	820919233982
