Description

Allen-Bradley 22C-D072A103

Allen-Bradleys 22C-D072A103 is a component of the PowerFlex 400 series, a line of adjustable frequency AC drives primarily designed for controlling speed and torque in various motor applications. The model focuses on enhancing user experience and operational efficiency.

Technical Features:

The Allen-Bradley 22C-D072A103, a model from the PowerFlex 400 series, comes with a range of technical specifications designed to meet various industrial requirements. This drive can deliver an output voltage ranging from 0 to 480 V AC, suitable for various motor applications.

Regarding input voltage, the 22C-D072A103 is designed to operate with an input range of 380 to 480 V AC. The drive is rated for a horsepower of 50, which indicates its capability to handle motors with substantial power requirements.

The 22C-D072A103 is designed for use with 3-phase power systems, which are common in industrial settings. Three-phase power is preferred in these environments due to its efficiency in delivering consistent power for heavy-duty motors and machinery.

In terms of control methods, the 22C-D072A103 utilizes both Volts per Hertz (V/Hz) and Sinusoidal PWM (Pulse Width Modulation). These control methods allow for precise and efficient regulation of motor speed and torque.

The drive is designed to handle an amperage of 72 Amps, correlating with its ability to manage high-power applications and the associated electrical load. Additionally, the drive includes a built-in communication port featuring RS485 connectivity systems.

Ambient Conditions:

The Allen-Bradley 22C-D072A103 drive is designed to operate optimally under specific ambient conditions, particularly regarding altitude, temperature, and cooling requirements. For altitude, the drive is most effective when situated at elevations lower than 1000 meters or approximately 3300 feet above sea level.

Temperature also significantly affects the drives operational efficiency. The 22C-D072A103 is engineered to function optimally within a temperature range of -10 to 45 degrees Celsius (14 to 113 degrees Fahrenheit). Furthermore, the drive utilizes a fan for its cooling mechanism, a key aspect of maintaining its operational integrity.

Control I/O Specifications:

The Allen-Bradley 22C-D072A103 drive has various input and output features that cater to diverse control needs in industrial settings. This drive, 22C-D072A103, includes seven digital control inputs. Four of these are fully customizable, allowing for a wide range of functionality based on user requirements. The remaining three digital inputs are semi-programmable, offering a degree of customization while retaining some predefined functions.

Regarding the output capabilities, the 22C-D072A103 features various control outputs to suit different operational needs. It includes two versatile programmable Form C outputs, which can be configured for various applications.

Frequently Asked Questions:

What is the storage temperature range for the 22C-D072A103?

The drive can be safely stored in temperatures ranging from -40 to 185 degrees Fahrenheit. This wide range ensures the drives components are protected under various storage conditions.

How is the input managed in the 22C-D072A103?

Input to the 22C-D072A103 is managed through an LCD keypad. This interface allows for easy programming, monitoring, and adjustment of the drives settings and functions.

What does Frame Size E mean for the 22C-D072A103?

Frame Size E refers to the drives physical dimensions and mounting specifications. It is part of a standardization system that helps identify the size and compatibility of the drive for installation purposes.

Product Specifications Table

Attribute	Specifications
Series	PowerFlex 400
Horsepower	50 HP
Voltage	480V AC
Dimensions	589 (23.19) H x 370 (14.57) W x 260 (10.24) D
Communication Interface	RS485
Frame Size	E
Ambient Temperature Range	-10 to 45 °C (14 to 113 °F)
Control Method	Sinusoidal PWM, Volts/Hertz control
Input/Output Frequency Range	Input: 48-63 Hz, Output: 0-320 Hz
Mounting Type	Panel Mount
