Allen-Bradley 22C-D170A103

Designed for fan and pump applications, the Allen-Bradley PowerFlex 400 22C-D170A103 is a high-performance AC drive with adjustable frequency. It belongs to the PowerFlex 400 series, providing various power ratings to accommodate industrial requirements.

Electrical Specifications:

The 22C-D170A103 model is a panel mount drive with a power rating of 90 kW (125 HP) and an output current of 170 A. It operates on a 380-480V AC, three-phase input voltage, and provides a full-rated output when connected to a three-phase supply. It works at a frequency range from 48 to 63Hz

Under typical conditions, the drive is 97.5% efficient at rated current, making it ideal for industry use. The drive also features an internal AC line reactor for 380-480V AC input, which helps improve the input power factor and reduce harmonic distortion. PowerFlex 400 frequency AC drive also has an isolated gate bipolar transistor.

Mechanical Specifications:

The drive can operate at a maximum altitude of 1000m without derating. At an altitude above 1000m, the drive derates 3% for every 305m. The temperature range 22C-D170A103 can operate without degrading is -10 to 45?. The device must be stored in “40-+85 °C. To avoid overheating, the PowerFlex 400 AC drives use fans to control the temperature.

The relative humidity of the drives enclosure should be within the 0 to 95%(noncondensing) range. The drive can withstand shocks of 15G peak for 11 ms duration (±1.0 ms) and vibrations of 1G peak, 5-2000 Hz while operating. The drive is engineered to meet the seismic requirements of the 2003 International Building Code. The drives design meets all industrial standards. The environmental conditions of industries are taken in consideration while setting the threshold of variables.

Communication Protocols

The 22C-D170A103 supports various communication protocols and a user-friendly interface to simplify programming and usage. The AC drive has parameter-selectable embedded protocols such as Modbus RTU, and P1-FLN, which dont require further integration or communication hardware. It supports Drive Serial Interface communication modules like EtherNet/IP, LonWorks, and BACnet.

The drive can easily be programmed with a PC using Integral RS-485 communications. It can also be used in a multidrop network configuration. Any controller with a DF1 port can be connected to the drive via a serial converter. The drive can be configured and monitored using optional software, such as Windows-based Pocket PC/Windows Mobile 2003

The drive features an integral keypad and a 2-line, 16-character LCD. Moreover, the LED indicators make system configuration and fault status monitoring easy. The drive is easy to handle and can be operated by any personnel. The text-based display and file management system of the drive software makes it very efficient and easy to use. The vast functionality like different language options and digital input design add to its versatility.

Frequently Asked Questions:

What protection features does the 22C-D170A103 drive offer?

The 22C-D170A103 drive provides comprehensive protection mechanisms, including electronic motor overload protection and bus overvoltage and undervoltage trips. It also has overcurrent protection up to 200% hardware limit and 300% instantaneous fault, ground fault, and short circuit trips on the drive output, ensuring the safety and reliability of connected equipment.

Where should the 22C-D170A103 drive be stored?

The adjustable frequency AC drive should be installed in the control cabinet of IP30, Type 1rating. Installing the drive in this cabinet protects it from dust and containments.

What types of digital inputs does the 22C-D170A103 drive have?

The 22C-D170A103 drive has three digital inputs that can be partly programmable and four completely programmable digital inputs. The semi-programmable inputs are dedicated to functions like stop, start, and SW enable.

Product Specifications Table

Attribute	Specifications
Input Voltage Range	380 - 480 V AC
Safety Features	Ground fault and short circuit protection
Output Current	208 A
Emission Class	Not filtered
Control Method	Sinusoidal PWM, Volts/Hertz
Ambient Operating Temperature	-10 to +50 °C
Cooling Method	Fan
Overload Capacity	150% for 1 minute
Analog Inputs	2 (0-10V, 4-20mA)
Motor Overload Protection	Class 10 motor overload protection
