Allen-Bradley 25A-D030N104
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 25AD030N104
- AC DRIVE
- POWERFLEX 523 SERIES
- 380-480 V AC
- 50/60 HZ
- THREE PHASE
- 20 HP (15 KW)
- IP 20 ENCLOSURE
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 25A-D030N104
| Brand | Allen-Bradley |
|---|---|
| Part Number/Catalog No. | 25A-D030N104 |
| Output Current | 30 A |
| Manufacturer | |
| Input Voltage: | 323-528 VAC |
| Input Phase: | 3-Phase |
| Output Voltage: | 0-460VAC |
| Output Power: | 20.0 HP (15.0 kW) Normal Duty; 15.0 HP (11.0 kW) Heavy Duty; |
| Embedded I/O: | Discrete Inputs: Five (5) Inputs Discrete Outputs: One (1) Form C Contacts Analog Input: One (1) Analog Input Analog output: One (1) analog output |
| Installation: | Panel Mount |
| Enclosure Rating: | IP20 / NEMA UL Open Type |
| Frame: | D |
| Control Method: | Volts / Hertz Control; Sensorless Vector Control; Sensorless Vector Economizer |
| Built-in communication port: | RS485 |
| Integrated Safety: | Safe-Torque Off (STO) functionality |
| Human Interface Module (HIM): | Yes; Standard HIM |
| Compatible Controllers: | CompactLogix; GuardLogix; ControlLogix |
| Series | PowerFlex 523 |
| Voltage | Three Phase, 480 VAC |
| Enclosure Type | IP20 NEMA / Open Type |
| Interface Module | Standard |
| Frame Size | Frame D |
| EMC Filtering Option | No Filtering |
