Name: Allen-Bradley 25B-D010N114
Brand: Warehouse
SKU: 25B-D010N114-FS
Price: 1190.0 USD
Availability: OutOfStock

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚… here.

25BD010N114
AC DRIVE
POWERFLEX 525
380 - 480 VOLT AC
4.0 KW
5 HP
10.5 AMP
NORMAL & HEAVY DUTY
FRAME B
EMC FILTER

Details on the Allen-Bradley 25B-D010N114

The Allen-Bradley 25B-D010N114 is an adjustable frequency drive. Like the 25B-D1P4N114, 25B-D010N104, and 25B-D013N104, it is part of the PowerFlex 525 family of products. This drive features a 3-phase input.

Principal Features and Benefits of the 25B-D010N114

The 25B-D010N114 has an output frequency range of 0 to 500 Hz. It regulates speed using various selectable control methods such as:

Volts/hertz
Sensorless vector control (SVC)
Closed loop velocity vector control
Permanent magnet motor control

25B-D010N114 Technical Specifications

The 25B-D010N114 has seven discrete inputs, two discrete outputs, two relay outputs, two analog inputs, and one analog output. Other specifications include:

EMC filter: Integrated
Input voltage: 380-480VAC
Output power: 4.0 kW (5.0 HP)
Output voltage: 0-460VAC
Output current: 10.5 A
Enclosure rating: IP20 / NEMA UL Open Type
Frame size: Frame B

25B-D010N114 Applications

The 25B-D010N114 controls the speed, torque, and energy consumption of motors. It can command motors to start, stop, go, forward, reverse, and jog. This drive is found in a wide range of applications, such as:

Conveyor systems
Blowers
Pumps
Machine tools

Installation and Configuration

You can mount the 25B-D010N114 vertically or horizontally on a flat, level surface. It supports premiere integration using Studio 5000 Logix Designer, and the output frequency is fully programmable.

Fast Shipping & Superior Customer Service

Purchase the 25B-D010N114 Now From Industrial Automation Co.

You can count on Industrial Automation Co. for the 25B-D010N114 you need. We have a wide range of industrial replacement parts in stock that are eligible for next-day delivery, all backed by our two-year warranty. Order yours today or submit a quick request quote.

Shop 25B-D010N114 Now

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition	SKU	Price	Warranty	Availability	Quantity	Purchase
Surplus Original Box	25B-D010N114-FS		2 Year Extended Warranty	Call for Availability		Call for Availability (877)-727-8757

Technical Specifications

Manufacturer	Rockwell Automation
Part Number/Catalog No.	25B-D010N114
Output Current	10.5 A
Brand	Allen-Bradley
Product Family:	PowerFlex 525 Adjustable Frequency AC Drive
Input Voltage:	380-480VAC
Input Phase:	3-Phase
Output Voltage:	0-460VAC
Output Power:	4.0 kW (5.0 HP)
I/O:	Discrete Inputs: Seven (7) Inputs Discrete Outputs: Two (2) Opto Outputs and Two (2) Relay Outputs Analog Input: Two (2) Analog Input Analog output: One (1) analog output
Installation	Panel Mount
Enclosure Rating:	IP20 / NEMA UL Open Type
Frame:	B
Control Method:	Volts / Hertz Control; Sensorless Vector Control
Built-in communication port:	RS485; Ethernet
Optional communication protocols:	ProfiBus; Ethernet; DeviceNet;
Integrated Safety:	Safe-Torque Off (STO) functionality
EMC Filter:	Integrated
Series	PowerFlex 525 Drive
Voltage	Three Phase, 480 VAC
Enclosure Type	IP20 NEMA / Open Type
Interface Module	Standard
Frame Size	Frame B
EMC Filtering Options	Filter
