Allen-Bradley 25B-D043N114

A member of the PowerFlex 525 series, the Allen-Bradley 25B-D043N114 is a versatile and durable frequency drive. This product is designed to provide high-performance motor control and is suitable for a variety of industrial applications. It is the preferred choice of professionals seeking quality and precision in motor control due to its compact design and sophisticated features, which guarantee efficient and reliable operation.

Technical Specifications:

Due to its 380-480VAC input voltage range, the Allen-Bradley 25B-D043N114 is suited for many industrial applications. This drive has a built-in EMC filter that ensures electromagnetic compatibility, improves operating dependability, and decreases interference.

The built-in Ethernet and RS485 ports allow for reliable and flexible integration of many networked systems. The IP20 enclosure grade and frame size E protect against dust and other tiny particles, ensuring a compact and safe installation.

The 25B-D043N114 panel mount installation is compact and easy to install. It produces 22 kW (30.0 HP) in ordinary operation and 18.5 kW (25.0 HP) in heavy-duty applications. The drives 43 A output current provides enough power for difficult motor control tasks.

This drive offers Volts/Hertz, Sensorless Vector Control (SVC), Closed-loop velocity vector control, and Permanent Magnet motor control, allowing accurate and adaptable control over a broad range of motor types and applications. The standard interface module simplifies configuration and monitoring, boosting usability and accessibility.

I/O Attributes:

The Allen-Bradley 25B-D043N114 provides a comprehensive array of I/O attributes to accommodate a wide range of application needs. It offers a wide range of control and automation capabilities, as it comprises seven discrete inputs. Furthermore, the drive is equipped with two relay outputs and two opto outputs, which provide the device with robust signal and control capabilities.

Analog inputs and outputs are also well-supported, with two analog inputs and one analog output available. These capabilities facilitate the precise monitoring and regulation of analog signals, thereby improving the drives performance and adaptability in intricate applications.

Safety:

Safety is paramount with the Allen-Bradley 25B-D043N114. The drives relay precharge limits inrush current during initiation, protecting the drive and related equipment. Dynamic braking from an inbuilt brake resistor increases operating safety and control.

The drives dual overload classification provides strong overload protection. It can resist a 110% overload for 60 seconds on normal duty and 150% for 3 seconds on heavy duty. It can also endure a 150% overload for 60 seconds or a 180% (200% programmable) overload for 3 seconds, providing excellent overload protection.

Additionally, the drive provides dynamic braking capabilities and motor speed control, which are essential for applications that necessitate rapid deceleration and precise speed adjustments. The StepLogic application enables the execution of basic position control duties that are both simple and effective. Additionally, the standard secure torque-off feature guarantees the safety of both personnel and equipment, facilitating speedier and safer restarting procedures.

Frequently Asked Questions:

What is the input voltage range of the Allen-Bradley 25B-D043N114?

The Allen-Bradley 25B-D043N114 is capable of functioning within an input voltage range of 380-480VAC. This range ensures compatibility with a diverse array of industrial electricity systems.

Is there an incorporated communication interface in the 25B-D043N114?

The Allen-Bradley 25B-D043N114 is, in fact, equipped with RS485 and Ethernet communication interfaces. The integration procedure into networked control systems is facilitated by these terminals.

What are the overload protection capabilities of the 25B-D043N114?

The Allen-Bradley 25B-D043N114 can endure a 110% overload for 60 seconds in the normal duty mode and a 150% overload for 3 seconds in the heavy-duty mode. It is also capable of withstanding a 150% overload for 60 seconds or a 180% overload for 3 seconds.
