Allen-Bradley 25B-V6P0N104
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.
- 25BV6P0N104
- AC DRIVE
- 1.1 KW (1.5 HP)
- 120 VAC INPUT
- 1 PHASE
- 50-60 HZ
- 6.0 AMP
- IP20
- UL-NEMA TYPE OPEN
- PANEL MOUNTING
- WITH BRAKE IGBT
- V PERHZ-SENSORLESS VECTOR-CLOSED LOOP VECTOR-PERM MAGNET MOTOR CONTROL
- SAFE TORQUE-OFF PID-SIL2 CAT 3
- SAFE TORQUE
- OFF PID
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 25B-V6P0N104
| Brand | Allen-Bradley |
|---|---|
| Part Number/Catalog No. | 25B-V6P0N104 |
| Output Current | 6.0 Amperes |
| Manufacturer | |
| Product Family: | PowerFlex 525 |
| Input Voltage: | 85-132 VAC |
| Input Phase: | 3-Phase |
| Output Voltage: | 0-230VAC |
| Output Power: | 1.5 HP or 1.1 kW |
| Embedded I/O: | Discrete Inputs: Seven (7) Sink / Source Discrete Outputs: One (1) N.O.; One (1) N.C. Contacts; Two (2) Digital / Optocoupler Analog Input: Two (2) Analog Input 0-10VDC; 0- 20mA Analog Output: One (1) Analog Input 0-10VDC; 0- 20mA |
| Installation: | Panel Mount |
| Enclosure Rating: | IP20 / NEMA UL Open Type |
| Frame: | B |
| Control Method: | V/Hz Control, Closed Loop Velocity Vector Control, Sensorless Vector Control (SVC) and Permanent Magnet Motor Control |
| Built-in communication port: | Ethernet; RS485 |
| Optional communication protocols: | ProfiBus; Dual-Ethernet; DeviceNet; |
| Integrated Safety: | Safe-Torque Off (STO) functionality |
| Human Interface Module (HIM): | Yes; Standard HIM |
| Compatible Controllers: | CompactLogix; GuardLogix; ControlLogix |
| Manufacturer | Allen Bradley / Rockwell Automation |
| Series | PowerFlex 525 Drive |
| Drive Category | PowerFlex 525 Adjustable Frequency AC Drive |
| Voltage | One Phase, 120 VAC |
| Part number | 25B-V6P0N104 |
| Input Voltage: | 100-120 VAC |
| Enclosure Type | IP20 NEMA / Open Type |
| Input phase: | 3-Phase |
| Interface Module | Standard |
| Output Phase: | 3-Phase |
| Frame Size | Frame B |
| Output Power | 1.5 HP or 1.1 kW; Normal and Heavy Duty |
| EMC Filtering Options | No Filter |
| Output current | 6.0 A |
| Discrete Input: | Six (6) digital inputs |
| Analog input: | Two (2) analog input |
| Discrete output | Two (2) relay output |
| Analog output | One (1) analog output (requires Series B hardware) |
| Braking | Built-in IGBT |
| EMC Filter | None Installed |
| Enclosure | IP20 NEMA/Open |
| Frame | A |
| Communication ports: | Ethernet I/P |
