Allen-Bradley 25C-D4P0N104

Allen-Bradley 25C-D4P0N104

Allen-Bradley 25C-D4P0N104

Allen-Bradley 25C-D4P0N104 is a PowerFlex 527 high-performance variable frequency drive. This drive enhances industrial automation operations with powerful functionality and versatile connectivity choices for dependable and efficient motor control.

Technical Specifications:

The Allen-Bradley 25C-D4P0N104 is diminutive, measuring 5.98 x 2.83 x 6.77 inches and weighing 2.4 pounds. The tandem Ethernet/IP connector of this model enables seamless integration into networked systems, as well as efficient data exchange and control.

The drive's output voltage, ranging from 0 to 460 VAC, can accommodate a wide range of motor requirements. Due to its absence of intrinsic EMC filtering, it is well-suited for applications that require external filtering. In industrial contexts, the open-type enclosure and A-sized frame make the installation and maintenance of drives simple.

With an output frequency range of 0 to 590 Hz, the 25C-D4P0N104 facilitates precise motor speed control, thereby increasing operational flexibility. It is compatible with a wide range of power supply systems due to the input supply voltage of 323–528 VAC. This device is equipped with two Ethernet/IP interfaces, which facilitate reliable network connectivity.

The Allen-Bradley 25C-D4P0N104 is capable of managing challenging industrial tasks due to its 4.0 Ampere output current and 2.0 HP or 1.5 kW output power, which are suitable for both standard and heavy-duty applications. Low heat production and energy efficiency are guaranteed by its 80-watt power dissipation.

Embedded I/O:

The 25C-D4P0N104 is designed to meet the diverse requirements of a variety of applications by providing a wide selection of embedded I/O options. It encompasses three semi-programmable and four fully programmable sink/source discrete inputs, which enable the creation of adaptable input configurations. The drive supports reliable signal transmission and control by providing two Form C contacts and one optocoupler output for discrete outputs.

Versatile options for analog signal processing are provided by the analog input capabilities of this drive, which include one unipolar –10 to 10V input and one bipolar 0 to 10V or 4 to 20 mA input. Furthermore, it is equipped with two analog outputs, each of which is capable of producing 0-10VDC or 0-20mA, which are capable of generating precise feedback and control signals for a variety of applications.

Ambient Environment:

The Allen-Bradley 25C-D4P0N104 is engineered to operate within specific environmental conditions in order to guarantee optimal performance and longevity. This unit should not be stored at temperatures that exceed 185 degrees Fahrenheit or fall below -40 degrees Fahrenheit. In order to prevent overheating and guarantee reliable functionality, the ambient air temperature encircling the drive must remain within the range of -4 to 122 degrees Fahrenheit during operating conditions.

Additionally, to prevent performance degradation, this drive should not be installed at altitudes exceeding 3300 feet. Derating may occur when the drive is operated above this altitude, which may impact its operational capabilities and efficacy.

Frequently Asked Questions:

Is EMC filtering included in the Allen-Bradley 25C-D4P0N104, and what is the frame size?

However, the 25C-D4P0N104 lacks integral EMC filtering and is equipped with an A-sized frame. This enables the implementation of adaptable external filtering solutions and facilitates the process of installation.

Do you know the output voltage and power ratings of the Allen-Bradley 25C-D4P0N104?

The 25C-D4P0N104 provides an output power of 2.0 HP or 1.5 kW and an output voltage range of 0-460 VAC. These classifications render it appropriate for both light-duty and heavy-duty operations.

What are the Allen-Bradley 25C-D4P0N104's operating temperature range and altitude restrictions?

The 25C-D4P0N104 is capable of operating efficiently within a temperature range of -4 to 122 degrees Fahrenheit and should not be installed at elevations exceeding 3300 feet. These conditions guarantee optimal efficacy and prevent derating.

Product Specifications Table:

Attributes Specification
Weight 2.4 pounds
Dimensions 5.98 x 2.83 x 6.77 inches
EMC Filtering Not included
Frame Size A
Input Voltage Range 323-528 VAC
Output Current 4.0 Amperes
Output Voltage Range 0-460 VAC
Output Power 2.0 HP / 1.5 kW
Operating Temperature Range -4 to 122 degrees Fahrenheit
Maximum Mounting Altitude 3300 feet

Allen-Bradley 25C-D4P0N104

Regular price
Sale price
$2,490.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley 25C-D4P0N104

Allen-Bradley 25C-D4P0N104 is a PowerFlex 527 high-performance variable frequency drive. This drive enhances industrial automation operations with powerful functionality and versatile connectivity choices for dependable and efficient motor control.

Technical Specifications:

The Allen-Bradley 25C-D4P0N104 is diminutive, measuring 5.98 x 2.83 x 6.77 inches and weighing 2.4 pounds. The tandem Ethernet/IP connector of this model enables seamless integration into networked systems, as well as efficient data exchange and control.

The drive's output voltage, ranging from 0 to 460 VAC, can accommodate a wide range of motor requirements. Due to its absence of intrinsic EMC filtering, it is well-suited for applications that require external filtering. In industrial contexts, the open-type enclosure and A-sized frame make the installation and maintenance of drives simple.

With an output frequency range of 0 to 590 Hz, the 25C-D4P0N104 facilitates precise motor speed control, thereby increasing operational flexibility. It is compatible with a wide range of power supply systems due to the input supply voltage of 323–528 VAC. This device is equipped with two Ethernet/IP interfaces, which facilitate reliable network connectivity.

The Allen-Bradley 25C-D4P0N104 is capable of managing challenging industrial tasks due to its 4.0 Ampere output current and 2.0 HP or 1.5 kW output power, which are suitable for both standard and heavy-duty applications. Low heat production and energy efficiency are guaranteed by its 80-watt power dissipation.

Embedded I/O:

The 25C-D4P0N104 is designed to meet the diverse requirements of a variety of applications by providing a wide selection of embedded I/O options. It encompasses three semi-programmable and four fully programmable sink/source discrete inputs, which enable the creation of adaptable input configurations. The drive supports reliable signal transmission and control by providing two Form C contacts and one optocoupler output for discrete outputs.

Versatile options for analog signal processing are provided by the analog input capabilities of this drive, which include one unipolar –10 to 10V input and one bipolar 0 to 10V or 4 to 20 mA input. Furthermore, it is equipped with two analog outputs, each of which is capable of producing 0-10VDC or 0-20mA, which are capable of generating precise feedback and control signals for a variety of applications.

Ambient Environment:

The Allen-Bradley 25C-D4P0N104 is engineered to operate within specific environmental conditions in order to guarantee optimal performance and longevity. This unit should not be stored at temperatures that exceed 185 degrees Fahrenheit or fall below -40 degrees Fahrenheit. In order to prevent overheating and guarantee reliable functionality, the ambient air temperature encircling the drive must remain within the range of -4 to 122 degrees Fahrenheit during operating conditions.

Additionally, to prevent performance degradation, this drive should not be installed at altitudes exceeding 3300 feet. Derating may occur when the drive is operated above this altitude, which may impact its operational capabilities and efficacy.

Frequently Asked Questions:

Is EMC filtering included in the Allen-Bradley 25C-D4P0N104, and what is the frame size?

However, the 25C-D4P0N104 lacks integral EMC filtering and is equipped with an A-sized frame. This enables the implementation of adaptable external filtering solutions and facilitates the process of installation.

Do you know the output voltage and power ratings of the Allen-Bradley 25C-D4P0N104?

The 25C-D4P0N104 provides an output power of 2.0 HP or 1.5 kW and an output voltage range of 0-460 VAC. These classifications render it appropriate for both light-duty and heavy-duty operations.

What are the Allen-Bradley 25C-D4P0N104's operating temperature range and altitude restrictions?

The 25C-D4P0N104 is capable of operating efficiently within a temperature range of -4 to 122 degrees Fahrenheit and should not be installed at elevations exceeding 3300 feet. These conditions guarantee optimal efficacy and prevent derating.

Product Specifications Table:

Attributes Specification
Weight 2.4 pounds
Dimensions 5.98 x 2.83 x 6.77 inches
EMC Filtering Not included
Frame Size A
Input Voltage Range 323-528 VAC
Output Current 4.0 Amperes
Output Voltage Range 0-460 VAC
Output Power 2.0 HP / 1.5 kW
Operating Temperature Range -4 to 122 degrees Fahrenheit
Maximum Mounting Altitude 3300 feet

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 25C-D4P0N104-R 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
