Allen-Bradley 2711-K5A2

The Allen-Bradley 2711-K5A2 is a robust and versatile PanelView 550 series operator interface terminal. This terminal, renowned for its simplicity and dependability, is intended to accommodate a wide range of industrial applications. Its compact design makes it optimal for environments in which space is at a premium.

Technical Specifications:

Allen-Bradley 2711-K5A2 operates on 120 Volts AC, making it compatible with most industrial electrical systems. Its 5.5-inch monochrome LCD blue mode screen is crisp and readable, and the 256 x 128-pixel screen produces a detailed and exact image.

The terminal is encased in a NEMA or IP-rated enclosure to protect it from dust, moisture, and other external variables in industrial situations. Its 14 x 11 x 8-inch size and 6-pound weight make the terminal portable and easy to install.

The 2711-K5A2s 240 KB non-volatile memory keeps critical data and settings even during power outages, improving operational dependability. The monochrome screens 4.75 x 2.38-inch display size is large enough for essential information and control activities.

A keypad input interface with 10 function buttons makes entering/navigating instructions on the terminal easy. The 2711-K5A2s inbuilt DH-485 communication interface allows smooth integration of various industrial devices and systems to boost automation and control.

Replaceable interior lighting distinguishes the Allen-Bradley 2711-K5A2. Regardless of lighting, the terminal can keep good functioning and visibility for a long time.

Installation:

The Allen-Bradley 2711-K5A2 is easy to install as a result of its ergonomic and compact design. Initially, verify that the mounting location satisfies the requisite NEMA or IP rating requirements to preserve the enclosures integrity. Ensure that the terminal is stable and precisely aligned by securing it in position with the corresponding mounting hardware.

The terminal should then be connected to the rated power supply. It is imperative to ensure that the power source is adequately grounded in order to prevent electrical hazards. Enable communication and data exchange by integrating the communication interface with the corresponding network or devices. After ensuring that all connections are secure, activate the terminal and adjust the settings to suit your specific application.

Safety Preventions:

To prevent the danger of electric shock, it is imperative to disconnect the power supply before conducting any installation or maintenance work on the terminal. Ensure that all wiring is securely connected and adheres to the specified standards.

Install the terminal in a NEMA or IP-rated location to avoid water, dust, and extreme temperatures. This extends terminal life and usefulness. Installation and maintenance should be done carefully to avoid damaging the terminals internal components or screen. Check the terminal for wear and damage and replace the internal lighting as needed to maintain operation and visibility.

Frequently Asked Questions:

What is the 2711-K5A2s enclosure rating and memory capacity?

The 2711-K5A2 is configured with a non-volatile memory capacity of 240KB and is enclosed in a NEMA or IP-rated enclosure. These features guarantee the retention of critical data and offer robust protection, even in the event of a power outage.

Allen-Bradley 2711-K5A2 terminal weight and dimensions?

The terminal is 14 x 11 x 8 inches and weighs 6 pounds. This compact dimension and manageable weight make it simple to install and integrate into a variety of control interfaces.

What input and communication ports does the 2711-K5A2 have?

The 2711-K5A2 is equipped with an embedded DH-485 communication port and a keypad input interface that includes ten function keys. These facilitate seamless network integration and user-friendly operation.

Product Specifications Table:
