Description

Allen-Bradley 2711-T5A5L1

The Allen-Bradley 2711-T5A5L1 is a standard operating terminal designed for industrial applications. Manufactured by Allen-Bradley, this operator terminal combines robustness with user-friendly features, making it suitable for a variety of operational environments. It offers a monochrome LCD blue mode display with a size of 5.5 inches, providing clear and concise visual feedback to the operator.

Technical Description:

The Allen-Bradley 2711-T5A5L1 is equipped with a touchscreen interface that has 128 touch cells arranged in 16 columns by 8 rows. The display resolution of this terminal is 256 x 128 pixels. The touch cell size is 26 x 30 pixels which facilitates accurate and responsive touch inputs.

The terminal has a heat dissipation rate of 20 W (69 BTU/hr). This makes it energy efficient and suitable for long-term operations. It comes with an application memory of 170 KB for application runtime and 240 KB nonvolatile RAM for storing application objects plus text and bitmaps. This allows for the handling of complex applications and data storage requirements.

The product operates on a 24 V DC power supply and supports an input voltage range of 18 to 30 V DC, with a 24 V DC nominal. It features an RS-232 (DH-485) communication port. The backlight of the terminal has a lifespan of 100,000 hours.

The terminal supports a variety of runtime objects such as control lists, numeric and keypad entry, scratch pad, list indicators, multi-state indicators, bar graph displays, analog gauges, numeric data displays, and message displays. These features enhance the terminal's versatility and make it suitable for diverse industrial applications.

Connectivity and Expansion:

It includes an RS-232 (DH-485) communication port. The terminal's internal memory is expandable using ATA memory cards with sizes ranging from 256 KB to 32 MB. This allows for scalability and the addition of more complex applications and data storage as needed.

The terminal can be equipped with additional components to improve its capabilities and user experience. These include anti-glare overlays, communication modules, and specific communication cables such as the 2711-NC13. The modular design allows for easy upgrades and customization to meet specific operational requirements.

Standard Mounting Instructions:

Mounting the Allen-Bradley 2711-T5A5L1 is straightforward. The terminal has specific dimensions for panel cutouts: a height of 125 mm (4.91 inches) and a width of 158 mm (6.20 inches). The terminal itself has a height of 152 mm (8.00 inches), a width of 185 mm (7.28 inches), an overall depth of 82 mm (3.20 inches), and a mounted depth of 64 mm (2.54 inches).

To mount the terminal, ensure the panel cutout matches the specified dimensions. Insert the terminal into the cutout, securing it with the appropriate fasteners. Ensure all connections are properly made, and the terminal is securely fixed to prevent any operational issues.

Frequently Asked Questions:

What is the connectivity option in the Allen-Bradley 2711-T5A5L1?

The Allen-Bradley 2711-T5A5L1 features an RS-232 (DH-485) communication port. This port ensures reliable data exchange with other industrial devices. It facilitates seamless connectivity in various applications.

What is the memory capacity of the Allen-Bradley 2711-T5A5L1?

The terminal has 170 KB application runtime memory and 240 KB nonvolatile RAM. It is also expandable using ATA memory cards up to 32 MB.

What is the display resolution and size of the 2711-T5A5L1?

The Allen-Bradley 2711-T5A5L1 features a 5.5-inch monochrome LCD display. The resolution is 256 x 128 pixels. This ensures clear and concise visual feedback for operators.

Product Specifications Table

Attribute Specifications
Series Panelview 550
Product Type Standard Operating Terminal
Display Size 5.5 inches
Display Resolution 256 x 128 pixels
Input Voltage Range 18…30V DC (24V DC nominal)
Operating Temperature Range 0 to 55 degrees Celsius
Communication Ports DH-485
Backlight Life 100,000 hours
Memory 170 KB application runtime; 240 KB nonvolatile RAM
Touch Cell Size 26 x 30 pixels

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 2711-T5A5L1-R 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
