Allen-Bradley 2711-T6C20L1
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.
- 2711T6C20L1
- DISCONTINUED BY MANUFACTURER 12/15/2014
- OPERATOR INTERFACE
- 24VDC
- PANELVIEW 600
- COLOR TERMINAL
- 6 INCH
- TOUCHSCREEN
- ETHERNET/IP COMMUNICATION AND RS-232 PRINTER PORT
- MOTHERBOARD: A77153-222-52
Repair & Service
Quick Repairs and Great Service
Quick Search
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 2711-T6C20L1
| Backlight | Field replaceable 50,000 hr 1/2 life at 25 °C (77 °F) |
|---|---|
| Input Type | Touch |
| Brand | Allen-Bradley |
| Manufacturer: | Rockwell Automation |
| Product Family: | PanelView Standard Terminals |
| Product Type: | PanelView 600 Standard Operator Terminals |
| Display Type: | Active Matrix TFT with Cold Cathode Fluorescent (CCF) Backlight |
| Display Area: | 115 x 87 mm (4.54 x 3.43 in.) |
| Resolution: | 320 x 240 |
| Touchscreen: | 128 (16 columns x 8 rows) |
| Touch Cell size: | 20 x 30 pixels |
| Application memory: | 190 KB application runtime 240 KB nonvolatile memory (application objects plus text and bitmaps) |
| Communication ports: | Ethernet; RS232 (printer) |
| Input Voltage range: | 18…32V DC (24V DC nominal supply) |
| Operating Temperature: | 0…55 ° C (32…131 ° F) |
| Heat Dissipation: | 24 W max (1.0 A at 24V DC) |
| Part Number/Catalog No. | 2711-T6C20L1 |
| Product Line | Panelview 600 |
| Display Size | 5 inches |
| Display Color | Color |
| Communication | EtherNet/IP and RS-232 Printer |
| Input Power | 18 to 32 Volts DC |
| Memory | 240 KB |
| Communication Cable | Ethernet cable |
| Shipping Weight | 4 pounds |
| Shipping Dimensions | 14 x 11 x 8 inches |
| Series | A, B, C, D, E, F, G, H, I, J, K, and L |
| UPC | 10611320575306 |
| Product Lifecycle Status* | Discontinued/Obsolete |
* The Allen Bradley 2711-T6C20L1 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-T6C20L1 units instead of migration.
