Allen-Bradley 2711-T6C2L1
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2711-T6C2L1
The Allen-Bradley 2711-T6C2L1 is a standard operating terminal from the Panelview 600 series. Designed for efficient and reliable operation, it is equipped with a color display and an array of user-friendly features.
This terminal is widely used in industrial applications where robust performance and ease of use are essential. It ensures seamless integration with various systems, providing an intuitive interface for monitoring and controlling processes.
Technical Description:
The 2711-T6C2L1 features an input voltage range of 18 to 32 V DC, with a nominal supply of 24 V DC. The terminal has a 5-inch display with a resolution of 320 x 240 pixels, offering clear and detailed visual output. The display area measures 115 x 87 mm (4.54 x 3.43 inches), providing ample space for effective data visualization. The display type is an active matrix TFT with a Cold Cathode Fluorescent (CCF) backlight.
This terminal comes with a touchscreen interface, comprising 128 touch cells arranged in 16 columns and 8 rows. The 2711-T6C2L1 also features an application memory of 190 KB for application runtime and 240 KB of nonvolatile memory. The memory specifications ensure smooth operation and adequate storage for various applications.
The heat dissipation for this terminal is rated at 24 W maximum (1.0 A at 24 V DC). It is equipped with DH-485 communication ports. The backlight is field-replaceable and has a lifespan of 50,000 hours at 25 degrees Celsius (77 degrees Fahrenheit).
Display and Input Specifications:
The display size of the Allen-Bradley 2711-T6C2L1 is 5 inches, with a color display that enhances user interaction and readability. The touchscreen input type supports intuitive navigation and control, making it easier for operators to interact with the system.
The terminal dimensions are 152 mm (6.00 inches) in height, 185 mm (7.28 inches) in width, and 96 mm (3.80 inches) in overall depth. The panel cutout dimensions are 125 mm (4.91 inches) in height and 165 mm (6.49 inches) in width.
Standard Operating Precautions:
When operating the Allen-Bradley 2711-T6C2L1, it is crucial to adhere to standard safety precautions to ensure optimal performance and longevity. Always verify the input voltage range before connecting the terminal to a power source.
Ensure that the operating environment temperature is within the specified range of 0 to 55 degrees Celsius. Regularly check the backlight status and replace it as needed to maintain display visibility. Properly secure the terminal in the panel cutout to prevent physical damage and ensure reliable operation .
Frequently Asked Questions:
What is the operating temperature range for the 2711-T6C2L1?
The Allen-Bradley 2711-T6C2L1 operates within 0 to 55 degrees Celsius. This range is suitable for most industrial environments. Ensure the temperature does not exceed these limits.
How much memory does the 2711-T6C2L1 have for applications?
The terminal has 190 KB for application runtime and 240 KB of nonvolatile memory. It stores application objects, text, and bitmaps efficiently. This ensures smooth operation.
What is the display resolution and type of the 2711-T6C2L1?
The display resolution is 320 x 240 pixels. It features an active matrix TFT with a CCF backlight. This provides clear and bright visuals.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Panelview 600 |
| Product Type | Operating Terminal |
| Display Size | 5 inches |
| Resolution | 320 x 240 pixels |
| Input Voltage Range | 18 to 32V DC |
| Memory | 190 KB runtime, 240 KB nonvolatile |
| Communication Ports | DH-485 |
| Operating Temperature | 0 to 55°C (32 to 131°F) |
| Touchscreen | 128 cells (16 columns x 8 rows) |
| Backlight | CCF, 50,000 hr lifespan |
