Allen-Bradley 2711P-RDT10C
Allen-Bradley 2711P-RDT10C
The Allen-Bradley 2711P-RDT10C is an exceptional-performance display module in the esteemed PanelView Plus 1000 series. This module is engineered to optimize operator interface applications by combining advanced touch technology with robust performance capabilities, guaranteeing dependable and efficient operation in industrial environments. It is well-suited for intricate automation tasks, as it establishes a seamless interface between automated systems and human operators.
Technical Specifications:
The Allen-Bradley 2711P-RDT10C runs on 100 to 240-volt AC, making it compatible with many power supply standards globally. Its 224 by 375-centimeter display area is tiny yet large enough for most control panels. This small size allows smooth integration into current control systems without any adjustments.
The 2711P-RDT10C uses 160 VA and is energy-efficient without losing performance. Low power consumption is crucial in industrial settings, where energy conservation may save money over time.
To provide smooth user interactions, the touch interface requires 10 to 110 grams of actuation force. Even with long-term use, this small actuation force reduces operator fatigue. One million touch interface actuations demonstrate the module's resilience and lifespan. Even in harsh industrial situations, this device's ruggedness ensures long-term reliability.
The 211 x 158-millimeter display accommodates operator inputs and excellent graphics. 18-bit color graphics improve interface readability and attractiveness by offering a bright display. The display's 300 cd/m ² brightness guarantees good visibility in various lighting settings for optimal use in various environments.
Precision and reliability are provided via an 8-wire analog resistive system for contact input. Due to its durability and ability to work in harsh settings, including dust, dirt, and rain, this technology is widely used in industry.
Calibration:
This display module with a touchscreen membrane requires calibration of the contact component. The operator terminal's touch settings are used to start calibration. The terminal performs a few simple processes that require operator input. Users must touch particular portions of the screen, usually the corners.
Aligning touch input with the UI maintains the module's efficacy and usability. To ensure touch input accuracy and efficiency, frequent calibrations are recommended.
Common Problems:
The Allen-Bradley 2711P-RDT10C display module often has little or no output. If the display is invisible and the brightness is maxed out, the display module must often be replaced. Routinely monitoring the device's working hours can help prevent issues. Other difficulties include touch screen calibration drifting, which may be fixed by recalibration, and membrane wear and tear, which may require replacement after extensive usage.
Preventive maintenance should be done regularly to reduce these issues. This includes power usage monitoring, touchscreen recalibration, and display luminance assessments to detect problems quickly. Clean working conditions prevent dust and dirt from affecting the touch screen's sensitivity and accuracy, extending the device's lifespan.
Frequently Asked Questions:
What is the Allen-Bradley 2711P-RDT10C's input voltage range and power consumption?
The Allen-Bradley 2711P-RDT10C has a maximum power consumption of 160 VA and operates within an input voltage range of 100 to 240 Volts AC. This guarantees energy efficiency and compatibility with a variety of power supplies.
What is the luminance and resolution of the Allen-Bradley 2711P-RDT10C display?
The luminance of the Allen-Bradley 2711P-RDT10C is 300 cd/m ², and its display resolution is 211 x 158 millimeters. Clear, sharp visuals that are readily discernible in a variety of illumination conditions are guaranteed by this combination.
What are the actuation force and touch input systems employed in the Allen-Bradley 2711P-RDT10C?
The Allen-Bradley 2711P-RDT10C employs an 8-wire analog resistive touch input system and necessitates an actuation force of 10-110 grams. This guarantees contact interactions that are both precise and responsive.
Product Specifications Table:
| Attributes | Specification |
|---|---|
| Input Voltage | 100 to 240 Volts AC |
| Dimensions | 224 x 375 millimeters |
| Power Consumption | 160 VA max |
| Actuation Force | 10-110 grams |
| Touch Interface Lifespan | 1 million actuations |
| Display Area | 211 x 158 millimeters |
| Resolution | 211 x 158 millimeters |
| Display Colors | 18-bit color graphics |
| Luminance | 300 cd/m ² |
| Touch Input | 8-wire analog resistive |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2711P-RDT10C
The Allen-Bradley 2711P-RDT10C is an exceptional-performance display module in the esteemed PanelView Plus 1000 series. This module is engineered to optimize operator interface applications by combining advanced touch technology with robust performance capabilities, guaranteeing dependable and efficient operation in industrial environments. It is well-suited for intricate automation tasks, as it establishes a seamless interface between automated systems and human operators.
Technical Specifications:
The Allen-Bradley 2711P-RDT10C runs on 100 to 240-volt AC, making it compatible with many power supply standards globally. Its 224 by 375-centimeter display area is tiny yet large enough for most control panels. This small size allows smooth integration into current control systems without any adjustments.
The 2711P-RDT10C uses 160 VA and is energy-efficient without losing performance. Low power consumption is crucial in industrial settings, where energy conservation may save money over time.
To provide smooth user interactions, the touch interface requires 10 to 110 grams of actuation force. Even with long-term use, this small actuation force reduces operator fatigue. One million touch interface actuations demonstrate the module's resilience and lifespan. Even in harsh industrial situations, this device's ruggedness ensures long-term reliability.
The 211 x 158-millimeter display accommodates operator inputs and excellent graphics. 18-bit color graphics improve interface readability and attractiveness by offering a bright display. The display's 300 cd/m ² brightness guarantees good visibility in various lighting settings for optimal use in various environments.
Precision and reliability are provided via an 8-wire analog resistive system for contact input. Due to its durability and ability to work in harsh settings, including dust, dirt, and rain, this technology is widely used in industry.
Calibration:
This display module with a touchscreen membrane requires calibration of the contact component. The operator terminal's touch settings are used to start calibration. The terminal performs a few simple processes that require operator input. Users must touch particular portions of the screen, usually the corners.
Aligning touch input with the UI maintains the module's efficacy and usability. To ensure touch input accuracy and efficiency, frequent calibrations are recommended.
Common Problems:
The Allen-Bradley 2711P-RDT10C display module often has little or no output. If the display is invisible and the brightness is maxed out, the display module must often be replaced. Routinely monitoring the device's working hours can help prevent issues. Other difficulties include touch screen calibration drifting, which may be fixed by recalibration, and membrane wear and tear, which may require replacement after extensive usage.
Preventive maintenance should be done regularly to reduce these issues. This includes power usage monitoring, touchscreen recalibration, and display luminance assessments to detect problems quickly. Clean working conditions prevent dust and dirt from affecting the touch screen's sensitivity and accuracy, extending the device's lifespan.
Frequently Asked Questions:
What is the Allen-Bradley 2711P-RDT10C's input voltage range and power consumption?
The Allen-Bradley 2711P-RDT10C has a maximum power consumption of 160 VA and operates within an input voltage range of 100 to 240 Volts AC. This guarantees energy efficiency and compatibility with a variety of power supplies.
What is the luminance and resolution of the Allen-Bradley 2711P-RDT10C display?
The luminance of the Allen-Bradley 2711P-RDT10C is 300 cd/m ², and its display resolution is 211 x 158 millimeters. Clear, sharp visuals that are readily discernible in a variety of illumination conditions are guaranteed by this combination.
What are the actuation force and touch input systems employed in the Allen-Bradley 2711P-RDT10C?
The Allen-Bradley 2711P-RDT10C employs an 8-wire analog resistive touch input system and necessitates an actuation force of 10-110 grams. This guarantees contact interactions that are both precise and responsive.
Product Specifications Table:
| Attributes | Specification |
|---|---|
| Input Voltage | 100 to 240 Volts AC |
| Dimensions | 224 x 375 millimeters |
| Power Consumption | 160 VA max |
| Actuation Force | 10-110 grams |
| Touch Interface Lifespan | 1 million actuations |
| Display Area | 211 x 158 millimeters |
| Resolution | 211 x 158 millimeters |
| Display Colors | 18-bit color graphics |
| Luminance | 300 cd/m ² |
| Touch Input | 8-wire analog resistive |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Introduction
The Allen-Bradley 2711P-RDT10C is a high-quality Display Module from the Panelview Plus 1000 series, designed for robust industrial use. It boasts a Windows CE 4.1 operating system, along with touchscreen input for a user-friendly experience. This display module is perfect for visualizing complex industrial processes with its 10.4-inch color display.
Technical Specifications for 2711P-RDT10C
The 2711P-RDT10C operates with a power consumption maximum of 160 VA and accommodates an input voltage range of 100 to 240 Volts AC. Its dimensions are broadly 224 x 375 millimeters, making it a compact yet powerful addition to any setup. Graphics capability stands at 18-Bit, ensuring clear and detailed visuals on its sizeable display.
Environmental Operating Requirements
Designed for industrial environments, the 2711P-RDT10C is housed in enclosures that meet NEMA, UL, or IP ratings, ensuring durability in a variety of operating conditions. This display module thrives in diverse industrial environments, thanks to its robust design and wide voltage range compatibility.
Parts and Configuration
The 2711P-RDT10C is engineered for efficiency, featuring RS-232 and Ethernet communication ports for connectivity and integration into a variety of networks. It supports FactoryTalk Machine Edition software, enhancing its performance and adaptability in complex automation tasks.
Enhanced Safety Features
With its commitment to reliability, the Allen-Bradley 2711P-RDT10C display module includes multiple safety and protection standards, ensuring secure operation under an extensive range of industrial conditions.
Discover the Difference with Allen-Bradley 2711P-RDT10C
Enhance your industrial processes with the Allen-Bradley 2711P-RDT10C. Shop now and upgrade your automation capabilities today.
