Description
The Allen-Bradley 2711P-RP6A is a robust CE logic module designed for the PanelView Plus CE terminals, featuring 128 MB of flash memory and RAM. It supports AC input voltage and offers versatile connectivity options, including an Ethernet port, a serial port, two USB ports, and a CompactFlash card slot. Designed to fit within a working temperature range of 0 to 55 degrees Celsius, it utilizes a Belden 7921A shielded Category 5e Ethernet cable for optimal performance over distances up to 100 meters. Proper installation and handling require careful attention to safety protocols to prevent damage or electric shock.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
The Allen-Bradley 2711P-RP6A is a logical module developed for PanelView Plus CE operator terminals. It takes AC input voltage and has 128 MB of flash storage and 128 MB of RAM embedded into it. It is interoperable with the ViewPoint application and has the marine certification. Before changing or installing any components, the connection to the terminal must be turned on. An electric shock or terminal harm could come from not doing this. When dealing with a module similar to this one, an ESD bracelet that is properly grounded should be worn, and the job should be done in a static-free area.
It includes status indicators, two USB sockets, an External memory card slot, an Ethernet interface, a serial port, and input connectors for AC power. The internal RAM & CompactFlash should be inserted before the logic module is linked to the display module if ordered individually. After rotating the logic module to remove the circuit panel, find the RAM module, remove the metal holding pins, pull out the RAM module, and then afterward slide in the new RAM module at an angle of 45 degrees.
The internal CompactFlash storage is installed or replaced by turning the module so that the circuit panel is exposed, removing the holding clip holding the CompactFlash card in place, pulling out the internal CompactFlash stick, replacing it with a new stick, and screwing the holding clip back on. To meet marine emission guidelines, a Belden 7921A insulated Class 5E Ethernet cable should be utilized. 100 meters is the longest Ethernet wire that can be used. This module's operating temperature range is 0 – 55 degrees Centigrade.
Manufacturer | Industrial Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 2711P-RP6A |
Product Type | Logic Module |
Series | CE Logic Modules for PanelView Plus CE Terminals |
Flash Memory | 128 MB |
RAM Memory | 128 MB |
Input | AC |
Features | Ethernet Port, Serial Port, 2 USB ports, and CompactFlash Card Slot |
Compatibility | Not Compatible with the PanelView Plus 6 Terminals |
