TECHNICAL SPECIFICATIONS

The Allen-Bradley 2711P-T10C22A9P is a visualization element that is a new and innovative version of operator terminals. With its lightweight and expandable hardware, it has cutting-edge features and abilities. It comes from the PanelView Plus 7 Performance graphical operator terminals product series.

The 10.4-inch display panel has an aspect ratio of 4:3, a viewable area of 211 × 158 millimeters (8.3 x 6.2 inches), and a display resolution of 800 by 600 SVGA featuring 18-bit colorful graphics, which allows process visualization. Its backlight has an active half-life of at least 50,000 hours and an average brightness of 300 cd/m2. The inbuilt analog-resistant touchscreen, which can withstand a maximum of one million presses with a force of 0.1 kilograms, is used for user input. To avoid damaging the touchscreen's surface, it is advised to use a plastic stylus or gloved fingers to use the device.

It is powered by a source with a frequency of 50 to 60 Hertz and a voltage range of 100–240 Volts. The enclosure for this unit should be NEMA & UL Type 13, 12, 5, and 4, UL-rated, and IP66-rated. Establish assembly clearances 2 inches at the top and bottom, 1 inch on both ends without needing an SC card, and 4 inches on both ends with the help of an SD card. Create a panel cutout that is 224 by 269 millimeters or 8.82 by 10.59 inches. Maintaining enough air flow by adhering to these clearances helps to avoid this module from overheating.

The Allen-Bradley 2711P-T10C22A9P has a colorful TFT display on its 10-inch SVGA touchscreen. Along with the machine's high power, having 512 MB of memory and 1 GB of RAM helps it run more effectively. The certifications for this device include Marine, INMetro, ATEX, NEMA (12, 13, & 4X), IP66, and IP54.

It is the PanelView Plus 7 graphical terminal from Allen-Bradley's high-performance line. This module provides a high-resolution screen featuring 18-bit color graphics. Additionally, it offers a VNC connection, so users can utilize it to access applications or programs from a distance and monitor them. About Ethernet connections, it has an inbuilt switch (DLR). It can run on voltages of 100 to 240 volts of alternating current. This module is 5.03 pounds in weight.
