Allen-Bradley 2711P-T12C4D8

Allen-Bradley 2711P-T12C4D8
Allen-Bradley 2711P-T12C4D8

Allen-Bradley 2711P-T12C4D8

The model 2711P-T12C4D8 of Allen-Bradley PanelView offers a reliable interface for industrial automation. It features a built-in depth of 55 mm. The front measures 363 mm in width and 282 mm in height. Wall mounting and direct mounting options are available. Cutout dimensions are 257 x 338 mm.

Technical Specifications:

The front side has a protection degree of NEMA 4X and IP65. It operates at temperatures from 0 °C to 55 °C. Heat dissipation is 240 BTU/hr. It withstands operating shock up to 15 G at 11 ms. The device can endure vibrations ranging from 10 to 500 Hz.

Relative humidity tolerance is 5 to 95% non-condensing. The device functions well up to the height of 2000 m. Nonoperating temperature ranges from -25 °C to 70 °C. IEC IP54, IP65, and NEMA/UL Type 12, 13, 4X are among the enclosure ratings.

The display area measures 246 x 184 mm. The device weighs approximately 3.2 kg. It has a color active-matrix TFT display with a screen diagonal of 12.1 inches. The display resolution is 800 x 600 pixels. Luminance is 300 cd/m2. The backlight uses CCFL technology and has a minimum lifespan of 50000 hours at 25 °C.

Operational and Installation Parameters:

The resistive touch screen technology is 8-wire analog. The operator input is touch-based. The Windows CE 6.0 is the operating system of PanelView without extended features. Version 6.0 or later of the FactoryTalk View Machine Edition software is compatible with this device. It is also compatible with FactoryTalk ViewPoint software version 1.2 or later. It has 512 MB RAM and 512 MB nonvolatile memory. Approximately 79 MB of memory is available for user projects.

The PanelView has an Ethernet interface supporting 10/100 Mbps, Auto-MDI/MDI-X. It includes one RS-232 port and two USB ports. DH+/DH-485, Ethernet, and ControlNet modules are examples of available communication options. It does not support protocols such as Modbus, DeviceNet, or PROFIBUS. The display type is a color active-matrix TFT, offering a vibrant and clear interface for users.

Safety Precautions:

The supply voltage is 24V DC nominal. Power consumption is 70 W max and 39 W typical. A recommended external power supply is Cat. No. 1606-XLE120E. The device includes a battery-backed clock for critical data timestamps. The battery can be replaced in the field with a coin-cell lithium battery (CR2032 or cat. no. 2711P-RY2032). The battery life is at least 4 years when used at 25 °C.

External storage options include a hot-swappable Secure Digital (SD) card, cat. no.1784-SDx, and USB flash drive. The high-speed, hot-swappable, 2.0 USB host ports facilitate both storage types. The Allen-Bradley 2711P-T12C4D8 model is designed for industrial applications requiring reliable and robust performance. The device is built to withstand harsh industrial environments, ensuring long-term durability and dependability for various automation needs.

Frequently Asked Questions:

What is the display size and resolution of the 2711P-T12C4D8 PanelView Model?

The Allen-Bradley PanelView 2711P-T12C4D8 features a 12.1-inch color active-matrix TFT display. The display resolution is 800 x 600 pixels which provides a clear and vibrant interface for users.

What are the mounting options available for the Allen-Bradley 2711P-T12C4D8 model?

The model 2711P-T12C4D8 offers wall mounting and direct mounting options. The cutout dimensions for installation are 257 x 338 mm, ensuring a secure and precise fit.

What is the operating temperature range for the Allen-Bradley PanelView 2711P-T12C4D8?

The Allen-Bradley 2711P-T12C4D8 operates in temperatures ranging from 0 °C to 55 °C. It can also function in relative humidity conditions of 5 to 95% non-condensing.

Product Specifications Table

Attribute Specifications
Number of HW-interfaces industrial Ethernet 1
Voltage Type DC
Screen diagonal 12.1 inch
Power consumption 70 W max (2.9 A at 24V DC), 39 W typical (1.6 A at 24V DC)
Display type Color active-matrix TFT
Memory 512 MB RAM, 512 MB nonvolatile memory, (approx. 79 MB free user memory)
Operating system Windows CE 6.0 operating system without extended features
Degree of protection (IP), front side IP65
Battery life 4 year minimum at 25 °C (77 °F)
Weight, approx 3.2 g

Allen-Bradley 2711P-T12C4D8

Regular price
$2,890.00
Sale price
$2,890.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley 2711P-T12C4D8

The model 2711P-T12C4D8 of Allen-Bradley PanelView offers a reliable interface for industrial automation. It features a built-in depth of 55 mm. The front measures 363 mm in width and 282 mm in height. Wall mounting and direct mounting options are available. Cutout dimensions are 257 x 338 mm.

Technical Specifications:

The front side has a protection degree of NEMA 4X and IP65. It operates at temperatures from 0 °C to 55 °C. Heat dissipation is 240 BTU/hr. It withstands operating shock up to 15 G at 11 ms. The device can endure vibrations ranging from 10 to 500 Hz.

Relative humidity tolerance is 5 to 95% non-condensing. The device functions well up to the height of 2000 m. Nonoperating temperature ranges from -25 °C to 70 °C. IEC IP54, IP65, and NEMA/UL Type 12, 13, 4X are among the enclosure ratings.

The display area measures 246 x 184 mm. The device weighs approximately 3.2 kg. It has a color active-matrix TFT display with a screen diagonal of 12.1 inches. The display resolution is 800 x 600 pixels. Luminance is 300 cd/m2. The backlight uses CCFL technology and has a minimum lifespan of 50000 hours at 25 °C.

Operational and Installation Parameters:

The resistive touch screen technology is 8-wire analog. The operator input is touch-based. The Windows CE 6.0 is the operating system of PanelView without extended features. Version 6.0 or later of the FactoryTalk View Machine Edition software is compatible with this device. It is also compatible with FactoryTalk ViewPoint software version 1.2 or later. It has 512 MB RAM and 512 MB nonvolatile memory. Approximately 79 MB of memory is available for user projects.

The PanelView has an Ethernet interface supporting 10/100 Mbps, Auto-MDI/MDI-X. It includes one RS-232 port and two USB ports. DH+/DH-485, Ethernet, and ControlNet modules are examples of available communication options. It does not support protocols such as Modbus, DeviceNet, or PROFIBUS. The display type is a color active-matrix TFT, offering a vibrant and clear interface for users.

Safety Precautions:

The supply voltage is 24V DC nominal. Power consumption is 70 W max and 39 W typical. A recommended external power supply is Cat. No. 1606-XLE120E. The device includes a battery-backed clock for critical data timestamps. The battery can be replaced in the field with a coin-cell lithium battery (CR2032 or cat. no. 2711P-RY2032). The battery life is at least 4 years when used at 25 °C.

External storage options include a hot-swappable Secure Digital (SD) card, cat. no.1784-SDx, and USB flash drive. The high-speed, hot-swappable, 2.0 USB host ports facilitate both storage types. The Allen-Bradley 2711P-T12C4D8 model is designed for industrial applications requiring reliable and robust performance. The device is built to withstand harsh industrial environments, ensuring long-term durability and dependability for various automation needs.

Frequently Asked Questions:

What is the display size and resolution of the 2711P-T12C4D8 PanelView Model?

The Allen-Bradley PanelView 2711P-T12C4D8 features a 12.1-inch color active-matrix TFT display. The display resolution is 800 x 600 pixels which provides a clear and vibrant interface for users.

What are the mounting options available for the Allen-Bradley 2711P-T12C4D8 model?

The model 2711P-T12C4D8 offers wall mounting and direct mounting options. The cutout dimensions for installation are 257 x 338 mm, ensuring a secure and precise fit.

What is the operating temperature range for the Allen-Bradley PanelView 2711P-T12C4D8?

The Allen-Bradley 2711P-T12C4D8 operates in temperatures ranging from 0 °C to 55 °C. It can also function in relative humidity conditions of 5 to 95% non-condensing.

Product Specifications Table

Attribute Specifications
Number of HW-interfaces industrial Ethernet 1
Voltage Type DC
Screen diagonal 12.1 inch
Power consumption 70 W max (2.9 A at 24V DC), 39 W typical (1.6 A at 24V DC)
Display type Color active-matrix TFT
Memory 512 MB RAM, 512 MB nonvolatile memory, (approx. 79 MB free user memory)
Operating system Windows CE 6.0 operating system without extended features
Degree of protection (IP), front side IP65
Battery life 4 year minimum at 25 °C (77 °F)
Weight, approx 3.2 g

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 2711P-T12C4D8-R $2,890.00 USD 2 Year Extended Warranty 1 In Stock in US!
