Allen-Bradley 2711P-T12W22D9P-BSHK

The 2711P-T12W22D9P-BSHK model of Allen-Bradley PanelView features a 12.1-inch widescreen display. It has a brightness of 417 cd/m² and a resolution of 1280 x 800 WXGA. The display type is TFT color with 18-bit graphics. The backlight is a solid-state white LED with a lifespan of 50,000 hours at 40°C. The devices robust build ensures long-lasting performance.

Technical Specifications:

The device measures 240 x 340 x 69.6 mm and weighs approximately 3.7 kg. The bezel is made of 316 stainless steel with a hygienic No. 4A finish. The gasket material adheres to the requirements of FDA 21 CFR 177.2600. The cutout dimensions are 218 x 312 mm that allow a precise installation. The analog resistive touch screen is rated for 1 million presses with a 100-gram operating force.

Memory specifications vary between Series A and Series B. Series B has 19.87 GB of storage and 4 GB of RAM, whereas Series A has 512 MB of RAM and 512 MB of storage. This memory configuration ensures smooth operation and ample storage for applications.

The real-time clock backup battery is a CR2032 lithium coin cell with a 4-year life at 25°C. Battery accuracy is ±2 minutes per month which provides reliable timekeeping. Two 10/100Base-T ports for DLR, linear, or star network topologies are included in the Ethernet connection. This enhances network flexibility and reliability.

Operational and Installation Parameters:

USB ports differ between series. Series A features two USB 2.0 host ports and one device port, while Series B has one USB 3.0 host port, one USB 2.0 host port, and one device port. Additionally, the gadget has an SD card slot that accepts 1784-SDx and 1784-SDHCx cards for external storage. These connectivity options facilitate data transfer and peripheral connections.

Series A operates on Windows CE 6.0 with extended features and MS Office Viewers. Series B runs Windows 10 IoT Core for facilitating a modern and secure operating environment. Electrical specifications include an input voltage of 24V DC nominal which ranges from 18 to 30V DC, and a power consumption of 50W maximum. To provide secure and effective power management, it supports 24V DC power supply from SELV and PELV.

Safety Precautions:

The Operating temperature lies between 0 to 55 °C, and non-operating temperature ranges from -25 to +70 °C. The unit is conformal-coated for additional protection. The Allen-Bradley PanelView 2711P-T12W22D9P-BSHK offers robust performance with its reliable display and extensive connectivity options. Proper installation and maintenance will ensure optimal performance and longevity of the device.

The Allen-Bradley PanelView 2711P-T12W22D9P-BSHK is a versatile and reliable interface solution. It is designed to meet the demanding requirements of industrial applications. The combination of advanced features and durable construction makes it a valuable addition to any industrial control system. Its comprehensive connectivity options and robust build quality provide a dependable interface for various applications.

Frequently Asked Questions:

What are the connectivity options available in the model 2711P-T12W22D9P-BSHK?

Two 10/100Base-T Ethernet ports, USB 2.0 and USB 3.0 host ports (depending on series), and an SD card slot for external storage are all included in the PanelView 2711P-T12W22D9P-BSHK. These options enhance data transfer and network connectivity.

What is the memory capacity of PanelView 2711P-T12W22D9P-BSHK?

The memory capacity varies by series. Series B has 19.87 GB of storage and 4 GB of RAM, whereas Series A has 512 MB of RAM and 512 MB of storage.

What is the display size and resolution of the Allen-Bradley PanelView 2711P-T12W22D9P-BSHK?

The Allen-Bradley PanelView 2711P-T12W22D9P-BSHK features a 12.1-inch widescreen display with a resolution of 1280 x 800 WXGA. It provides 18-bit color graphics for ensuring clear and vibrant visual output.
