Allen-Bradley 2711P-T15C22D9P
All products (new, refurbished, and repairs) are covered by the Industrial Automation Co.'s 2-year warranty. Manufacturer’s warranty is void and does not apply. Review our Warranty notice here.
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Review our Product Conditions notice here.
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 2711PT15C22D9P
- OPERATOR INTERFACE
- PANELVIEW PLUS 7
- PERFORMANCE COLOR TERMINAL
- TFT 15-INCH XGA TOUCH SCREEN
- SINGLE ETHERNET PORT
- 24V DC POWER
- WINDOWS CE OS LICENSE PRO
- PERFORMANCE MODEL
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
TECHNICAL SPECIFICATIONS
The Allen-Bradley 2711P-T15C22D9P is a performance operator terminal that belongs to PanelView Plus 7 product series. Its main characteristics are the 15-inch colorful TFT display panel, dual Ethernet communication ports, and touch interface.
This module's digital display has a viewable range of 304 × 228 millimeters (12.0 × 9.0 inches.), 1024 × 768 XGA display resolution, and 18-bit color graphics functionality. This display panel has a 4:3 aspect ratio and a 300 cd/m2 backlight that normally provides high illumination. The solid-state, white light-emitting diode used in this backlight has a minimum half-life of 50,000 hours when used at around 40 °Centigrade (104 °Fahrenheit). The analog-resistant touch-sensitive cells that make up the touchscreen interface are intended to actuate approximately one million presses with an actuating pressure of 0.1 kilograms. It is advised to use a plastic stylus or gloved finger to handle this module.
If necessary, screen maintenance and upkeep can be done. The display screen has calibration, brightness, contrast, and screen saver features. These changes increase the backlight's working life, enhancing the terminal's utility.
Its required supply voltage ranges from 18 to 32 Volts, and its maximum power usage for 24 V DC is 50 W or 2.1 A. Physically, this module measures 318 (H) × 381 (W) × 69.6 (D), and otherwise 12.52 (H) × 15.00 (W) × 2.74 (D) millimeters. The panel cutout needed to install this Allen-Bradley module is 290 (H) by 353 (W), and otherwise 11.42 (H) × 13.90 (W) millimeters.
External flash drives or memory cards from Allen-Bradley, model numbers 1784-SDx and 1784-SDHCx, may be connected to the host USB port to activate it. The external Dc power range for this module is 18–30 VDC. Double Ethernet communication interfaces that can be used to connect to or implement Linear, Star, and Ring topologies are already incorporated into the Allen-Bradley 2711P-T15C22D9P. The configuration environment launched the FactoryTalk View Computer Version runtime, which uses an enhanced version of the Windows operating system to execute the HMI program.
