Allen-Bradley 2711P-T7C22D9P

The Allen-Bradley 2711P-T7C22D9P is a high-performance PanelView Plus 7 Standard series operator interface designed to offer efficient control and monitoring capabilities in industrial automation environments. This model is optimal for applications requiring a user-friendly and robust interface, as it is recognized for its advanced features and reliability.

Technical Specifications:

The Allen-Bradley 2711P-T7C22D9P is 2.65 pounds and operates at a power consumption of 50 watts. The voltage range of its input is 18-30 VDC. The terminals 6.5-inch display size ensures a clear and compact viewing experience. The displays illumination is a CCFL that is LED-based and has a lifespan of 50,000 hours.

The display is a color Active Matrix TFT LCD, which guarantees an accurate and vibrant representation of color. Ample space is provided to display detailed information, as the display area measures 132 x 99 mm.

An analog resistive touchscreen facilitates operator input, enabling precise control with an operating force of 100 grams. Due to its 50,000-hour lighting lifespan, the Allen-Bradley 2711P-T7C22D9P requires less maintenance.

The Allen-Bradley 2711P-T7C22D9P is designed to operate efficiently and reliably in challenging environments. This terminal provides precise and detailed visuals with the color active matrix TFT LCDs brilliant visuals, and the 640 x 480 SVGA resolution makes data accessible to read.

Memory:

The 2711P-T7C22D9P includes substantial memory capabilities. It is equipped with 512 MB of RAM and 512 MB of storage for applications, ensuring smooth performance and ample space for storing critical data.

Allen-Bradley 2711P-T7C22D9P offers 80 MB of user memory, providing sufficient capacity for user-specific files and settings. The terminal can handle complicated tasks and massive data quantities without slowing down, enabling industrial customisation and flexibility.

Communication Protocols:

Its support for various communication protocols further enhances the terminals connectivity capabilities. It has three USB ports, one RS232 connector, and one Ethernet port. The Ethernet interface facilitates the implementation of versatile network configurations by supporting Linear, Device Level Ring (DLR), and Star topologies.

It effectively communicates with Allen-Bradley Logix controllers and older controllers like the SLC500 and MicroLogix. The Ethernet port can support transmission frequencies of 10/100 Mbps and auto-negotiation, guaranteeing reliable and efficient data communication.

The Allen-Bradley 2711P-T7C22D9P three USB ports make connecting mice, keyboards, and external storage devices easy. Since the RS232 connector allows legacy device integration, the terminal can be easily incorporated into existing systems.

Allen-Bradleys 2711P-T7C22D9P terminal is powerful and versatile, making it suitable for various uses in industry. This terminal meets modern industrial needs with a high-resolution display, vast memory, and flexible communication options, providing reliable and efficient control and monitoring.

Frequently Asked Questions:

What is the display resolution and size of the Allen-Bradley 2711P-T7C22D9P?

The Allen-Bradley 2711P-T7C22D9P has a display dimension of 6.5 inches and a 640 x 480 SVGA resolution. This combination guarantees distinct and detailed visuals for an optimal operator interface.

How much power does the Allen-Bradley 2711P-T7C22D9P consume, and what is its weight?

The 50-watt Allen-Bradley 2711P-T7C22D9P weights 2.65 pounds. Its lightweight design and economical energy usage boost the devices performance and make it easy to install and manage.

What types of communication ports are available on the Allen-Bradley 2711P-T7C22D9P?

The Allen-Bradley 2711P-T7C22D9P has an Ethernet port, three USB ports, and one RS232 connector. These adaptable communication options simplify data integration and exchange in various industrial environments.
