TECHNICAL SPECIFICATIONS

Revolutionize Your Industrial Automation with the Allen-Bradley 2711P-T12W22D9P PanelView Operator Terminal

Seamless Integration and Superior Communication

The Allen-Bradley 2711P-T12W22D9P is a pinnacle of engineering in industrial automation. This advanced operator terminal stands out as a critical component in modern industrial settings, offering unparalleled real-time data exchange and seamless communication. It effortlessly interfaces with Programmable Automation Controllers (PAC), Programmable Logic Controllers (PLC), and a wide array of compatible devices, ensuring a streamlined and efficient operation.

Vivid Display and Intuitive Interaction

Experience visual clarity like never before with the terminal's striking 1280 x 800 WXGA widescreen monitor, boasting 18-bit color graphics for vivid, detailed displays. The integrated analog resistive touchscreen, rated for over one million actuations, offers a responsive and intuitive interface for operators, making interaction both effortless and precise.

Robust Networking Capabilities

Equipped with dual Ethernet ports, this Human Machine Interface (HMI) device is a hub of connectivity. It supports diverse network topologies such as DLR (Device Level Ring), Linear, and Star, enabling flexible communication with additional automation devices and enhancing network resilience.

Durable and Versatile Installation

Designed for reliability, the 2711P-T12W22D9P can be flush-mounted in enclosures classified as IP66 by UL, and it meets NEMA and UL Types 12, 13, and 4X standards. Its ability to support both horizontal and vertical positioning, along with a static screen rotation feature, adds to its installation versatility.

Optimal Performance in Extreme Conditions

Engineered to perform in challenging environments, this terminal operates flawlessly at altitudes up to 2000 meters (6562 feet) and within a temperature range of 0 to 55 °C (32 to 131 °F). Its robust build ensures reliability in conditions with humidity ranges of 5 to 95% non-condensing, and it withstands significant operating shock and vibration.

Advanced Operating System and Application Support

Powered by Windows Compact Embedded (CE), the terminal supports a plethora of functionalities including FTP, Active-X, VNC, remote desktop, PDF, and file viewers. Its compatibility with FactoryTalk View Machine Edition allows for the creation and download of sophisticated HMI applications, enhancing operational efficiency and control.

Connectivity and Storage Excellence

The terminal is equipped with a versatile range of ports, including 1 SD card slot, 2 high-speed USB ports, and 1 audio port, complemented by 512 MB of internal RAM and 512 MB of flash memory. Its rear LEDs provide immediate diagnostics for efficient troubleshooting.

Remote Access and Control

With support for FactoryTalk ViewPoint software version 1.2 or later, remote access and control of applications are seamless. Its compatibility with FactoryTalk View Machine Edition version 8 or later ensures robust operation and monitoring capabilities.

Ergonomic and User-Friendly Design

The 16:10 widescreen TFT touchscreen display, measuring 12.1 inches diagonally, is designed for an optimal user experience. It supports a variety of touchscreen gestures, including long presses, taps, drags, and double-taps. Weighing just 2.54 kg and with dimensions of 24.6 cm x 13.39 cm x 6.9 cm, it integrates smoothly into your existing system setup.

Your Industrial Operations Redefined

The Allen-Bradley 2711P-T12W22D9P is not just a component; it's a cornerstone of efficient, reliable, and intuitive industrial automation. Embrace the future of industrial operations with this state-of-the-art operator terminal.
