Allen-Bradley 2711PC-T6M20D
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 2711PC-T6M20D is a robust monochrome compact operator terminal within the PanelView Plus series, optimized for small to medium industrial applications. It features a grayscale passive matrix touchscreen with a resolution of 320 x 240 pixels and a display brightness of 300 cd/m², with a diagonal screen size of 112mm by 84mm. This terminal offers up to 25 HMI display screens and accommodates 200 alarm messages, supported by 20 MB of user memory and expandable with a CompactFlash card up to 512 MB. Engineered for reliability, the device includes a real-time clock (accuracy of +/- 2 minutes per month) with a battery backup expected to last up to five years at 25°C, alongside LED indicators for communication status and faults. Operating at 18-30 VDC with a power draw of 25 W and an electrically efficient design, it can function in temperature ranges between 0 and 55 °C and endure altitudes up to 2000 meters without derating. The robust construction meets various certification standards including c-UL-us, CE, and C-Tick and is suitable for enclosures offering NEMA Type 12, 13, and 4X protection for indoor use, as well as IP54 and IP65 ratings.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711PC-T6M20D |
| Product Line | PanelView Plus 6 Compact |
| Display Size | 4.4 x 3.3 in. |
| Display Color | Monochrome |
| Input Type | Touchscreen |
| Communication | Ethernet and RS-232 |
| Input Power | 24V DC |
| Software | FactoryTalk View Compact Machine Edition |
| Memory | 512 MB nonvolatile memory and 256 MB RAM |
| Enclosure Type | NEMA/UL Type 12, 13, 4X (indoor use only), and IEC IP66 |
| Dimensions | 6.0 x 7.28 x 2.86 in. |
