The Allen-Bradley 803-PL12 Rotating Cam Limit Switch is designed for robust industrial applications, facilitating precise cyclic operations in processes such as packaging, assembling, steel forming, and injection molding. Housed in a NEMA Type 1 enclosure, it features a standard left shaft extension with a 400 RPM base speed shaft equipped with oversized ball bearings. This device offers 12 cam-operated circuits, each with independently adjustable cam assemblies, and supports both AC and DC ratings with 25 A Normally-Closed contacts that are actuated by a cam-roller mechanism. The switch provides a flexible cam duration range of 11 to 349 degrees, allowing for intricate control over contact timing and dwell period based on cam positioning, and operates effectively within a temperature range of -30 to 66 degrees Celsius. With a net weight of 13.6 kg and dimensions of 483.3 x 181 x 138.1 mm, the 803-PL12 is certified by CE, CSA, and UL, underscoring its reliability and compliance with industry standards.
