Allen-Bradley MPL-A1530U-VJ42AA

The Allen-Bradley MPL-A1530U-VJ42AA servo motor, part of the MPL series, is a premium permanent magnet rotary servo motor designed for high-performance industrial applications. It represents a state-of-the-art solution for industrial servo applications, combining compact design with high torque output, advanced feedback technology, and robust construction tailored to meet the rigorous demands of modern automation systems.

Technical Specifications:

Operating at a voltage class of 200V AC, the motor is designed for efficiency and optimal performance within industrial environments. It incorporates innovative winding technology that enables it to deliver up to 40% higher torque per unit size compared to traditional servo motors.

This motor features a compact 63 mm frame size and utilizes low inertia technology. It offers a remarkable torque-to-size ratio that is suitable for demanding motion control tasks.

Constructed with a low inertia design, the Allen-Bradley MPL-A1530U-VJ42AA boasts a robust 3-inch magnetic stack length and operates at a rated speed of 7000 rpm. It incorporates a high-efficiency brushless AC design, enhancing reliability and reducing maintenance requirements. The motor is equipped with Smart Motor Technology, which includes onboard memory to store motor identity and facilitate seamless communication with control systems during startup, thereby streamlining commissioning processes.

The Allen-Bradley MPL-A1530U-VJ42AA is equipped with a multi-turn high-resolution encoder featuring a 128 sin/cos absolute feedback protocol using the Hiperface interface. This advanced feedback system ensures precise positional accuracy and responsiveness, which is crucial for high-speed and high-precision applications.

Environmental and Compliance Standards:

The Allen-Bradley MPL-A1530U-VJ42AA is designed to operate reliably in temperatures ranging from 0°C to 40°C, ensuring consistent performance in typical industrial settings.

It complies with UL and CSA standards, making it suitable for use in both North American and international markets. The motor is CE marked, indicating conformity with applicable European Union directives for electrical equipment.

Featuring an IEC metric mounting flange, the motor offers straightforward integration into various automation systems and machinery configurations. It comes equipped with a shaft key and does not include a shaft seal, simplifying the process of connecting the motor to driven equipment.

Safety Precautions:

When working with the Allen-Bradley MPL-A1530U-VJ42AA, it is essential to adhere to safety protocols to ensure both personal safety and the longevity of the equipment. Before installation or maintenance, ensure that all power to the motor is isolated correctly and locked out according to established lockout/tagout procedures.

The servo motor includes rotating parts and can generate significant torque during operation. Always de-energize and confirm that the motor is completely stopped before performing any maintenance or adjustments.

The Allen-Bradley MPL-A1530U-VJ42AA features enhanced thermal management capabilities. However, during operation, it can still generate heat. Ensure proper ventilation and cooling mechanisms are in place to prevent overheating, which can affect motor performance and longevity.

Frequently Asked Questions:

What is the horsepower rating of the Allen-Bradley MPL-A1530U-VJ42AA?

The Allen-Bradley MPL-A1530U-VJ42AA has a horsepower rating of 0.5 Hp. This rating indicates the motors capacity to deliver mechanical power based on its torque and speed characteristics.

What is the magnetic stack length of the Allen-Bradley MPL-A1530U-VJ42AA?

The Allen-Bradley MPL-A1530U-VJ42AA has a length of 3 inches. This makes the motor ideal for integration into industrial machinery and automation systems.

sWhat is the mounting type of the Allen-Bradley MPL-A1530U-VJ42AA?

The Allen-Bradley MPL-A1530U-VJ42AA features an IEC metric mounting flange, which is standard for this motor series. This mounting type ensures compatibility and ease of integration into various industrial automation applications.
