Allen-Bradley MPL-B330P-MJ72AA
Allen-Bradley MPL-B330P-MJ72AA
The Allen-Bradley MPL-B330P-MJ72AA servo motor, a component of the distinguished MP Series Low Inertia servo motors brought by Rockwell Automation.
Designed to serve a multitude of applications such as packaging, converting, material handling, electronic assembly, and automotive, this premium permanent magnet rotary servo motor exemplifies versatility and outstanding performance.
Technical Specifications:
The Allen-Bradley MPL-B330P-MJ72AA is part of the MP Series Low Inertia servo motors, designed for dynamic and high-speed applications requiring precise motion control. The frame size of 100 mm (Frame size 3) is well-balanced to accommodate compact machine designs.
The servo motor is engineered for systems requiring 400VAC, making it suitable for a wide range of industry standards. It delivers a sturdy output with a rated power of 1.8 kW, along with a high rated speed of 5000 rpm, ensuring operations are swift and timely.
The Allen-Bradley MPL-B330P-MJ72AA is also characterized by a low-inertia series type, which promotes faster acceleration and deceleration for dynamic applications. It seamlessly integrates with an extensive range of Kinetix servo drives, including the Kinetix 5500, 5700, 6200/6500, 6000, 300/350, 2000, and 7000.
This versatile module features a circular (SpeedTec) DIN connector with a right angle thats 180° rotatable, offering flexible, secure connections and straightforward installation. The servo motor comes with a 1024 sin/cos, absolute multi-turn encoder that utilizes Hiperface protocol for precise motion control and feedback.
This versatile module comes with a Type FF mounting facility, making it easier to integrate into various setups. With a shaft key and without a seal, it is engineered for easy integration and durability.
Operational and Installation Parameters:
The Allen-Bradley MPL-B330P-MJ72AA servo motor is designed for easy and efficient installation. The motor should be installed in a dry and clean environment, free of dust and corrosive materials. Ensure that the motor is securely mounted, and the connectors are correctly fitted.
Its also important to note that the motors performance parameters that align with the requirements of the driven equipment. Always ensure that the motor is paired with compatible Kinetix servo drives to guarantee optimal performance and longevity.
Safety Precautions:
The motor should only be installed by trained and qualified personnel, following the manufacturers guidelines. Always disconnect the motor from the power supply before performing any maintenance or adjustments, to safeguard against electrical shocks.
Its recommended to wear appropriate personal protective equipment (PPE) during installation and maintenance. Avoid direct contact with the motor during operation, as surfaces may become hot and could result in burns.
In an event of any malfunction, immediately disconnect the motor from the power supply and seek professional assistance. Remember that neglecting safety precautions could result in serious injury or damage to the motor.
Frequently Asked Questions:
What is the operational temperature range of the Allen-Bradley MPL-B330P-MJ72AA servo motor?
The operational temperature range for the Allen-Bradley MPL-B330P-MJ72AA servo motor is -20°C to +40°C, ensuring reliable performance across a wide array of working environments.
What voltage range does the Allen-Bradley MPL-B330P-MJ72AA servo motor support?
The Allen-Bradley MPL-B330P-MJ72AA servo motor is designed for systems requiring 400 Volts AC, aligning with a wide range of industry standards.
How fast can the Allen-Bradley MPL-B330P-MJ72AA servo motor operate?
The Allen-Bradley MPL-B330P-MJ72AA servo motor boasts a high rated speed of 5000 revolutions per minute (rpm), ensuring swift and timely operations.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | MP Series |
| Horsepower | 2.81 hp |
| Voltage | 400 VAC |
| RPM | 5000 |
| Frame Size | 100 m |
| Encoder | 1024 sin/cos |
| Ambient Temperature Range | -20-40 C |
| Control Method | Hiperface protocol |
| Connector | (Speed tech) DIN Conector |
| Mounting Flange | IEC metric |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
