Description

Allen-Bradley MPL-B420P-MJ22AA

The Allen-Bradley MPL-B420P-MJ22AA is a high-efficiency servo motor for precision control in automated systems. It integrates seamlessly with Allen-Bradleys Kinetix servo drives, providing high-resolution feedback for accurate positioning.

Technical Features:

The Allen-Bradley MPL-B420P-MJ22AA operates within a 400-volt AC voltage class, making it suitable for diverse industrial applications. With a frame size of 115 millimeters, it delivers significant power output and can integrate into different system configurations seamlessly.

Featuring a magnetic stack length of 2 inches, the MPL-B420P-MJ22AA motor provides efficient magnetic flux, ensuring optimal performance. Its design effectively balances compactness and power, making it perfectly suited for precise control tasks in automation and manufacturing settings.

The servo motor Allen-Bradley MPL-B420P-MJ22AA is designed without an integrated brake, making it versatile for various industrial automation and manufacturing scenarios.

The mounting flange complies with the IEC metric standard, ensuring compatibility with international equipment and systems. This model MPL-B420P-MJ22AA also includes standard factory-designated options, highlighting its readiness for straightforward integration into various automation setups without requiring custom modifications.

Moreover, the motor is designed with a shaft key, facilitating easy and secure attachment of mechanical components. The absence of a shaft in the Allen-Bradley MPL-B420P-MJ22AA seal ensures smooth operation, enhancing its suitability for various industrial applications.

Equipped with circular bayonet connectors facing the shaft, this motor allows quick and reliable electrical connections. This design feature in MPL-B420P-MJ22AA enhances ease of integration into various systems, supporting efficient installation and maintenance processes in complicated industrial environments.

Ambient Conditions:

The MPL-B420P-MJ22AA motor is engineered to perform optimally within specific ambient conditions, ensuring durability and efficiency.

The motor MPL-B420P-MJ22AA operates effectively from 0 to 40°C (32 to 104°F), ensuring reliable function in various conditions. The Allen-Bradley MPL-B420P-MJ22AA can tolerate a wider temperature range, from -30 to 70°C (-22 to 158°F) for storage. This flexibility in storage conditions aids in inventory management and transport, minimizing the risk of damage due to temperature variations.

The motor is designed to operate in relative humidity levels between 5% and 95% non-condensing. This wide humidity range ensures that the MPL-B420P-MJ22AA can function in diverse moisture levels without compromising its internal components due to condensation.

Safety & Precautions:

When using the Allen-Bradley MPL-B420P-MJ22AA servo motor, always disconnect power before installation, maintenance, or inspection to prevent electrical shocks or accidental startup. Also, ensure the motor is properly grounded to avoid electrical hazards.

During installation, verify that all mechanical connections are secure and aligned correctly to prevent excessive vibration or mechanical failure. Use appropriate lifting techniques and equipment to handle the motor, considering its weight and size.

Frequently Asked Questions:

What is the designated rated speed of the MPL-B420P-MJ22AA, and which applications are most suitable for this motor?

The Allen-Bradley MPL-B420P-MJ22AA boasts a rated speed of 5000 RPM. This impressive high-speed capability makes it perfect for applications demanding rapid and precise movements, including robotics, automated assembly lines, and high-speed machining processes.

What type of feedback system does the Allen-Bradley MPL-B420P-MJ22AA use?

The MPL-B420P-MJ22AA features a multi-turn high-resolution encoder for feedback. This advanced feedback system provides accurate position and speed data for precise motor control.

What are the installation requirements for the Allen-Bradley MPL-B420P-MJ22AA to ensure optimal performance and longevity?

The MPL-B420P-MJ22AA must be installed securely, free from corrosive materials. Ensuring the motor is protected from corrosive environments prevents damage to its components and extends its lifespan.

Product Specifications Table

Attribute	Specifications
Series	MP-Series Low-inertia Servo Motor
Voltage	460 V
Dimensions	Frame Size 4 (115 mm), Stack Length 20 (50.8 mm)
Mounting Type	IEC Metric, Free Mounting Holes (Type FF)
Product Status	Active
Ambient Temperature Range	0 to 40°C (32 to 104°F)
Torque	Continuous Stall Torque: 4.7 Nm, Peak Stall Torque: 14.1 Nm
Communication Interface	SpeedTEC DIN Connector, Right Angle, 180 Degrees Rotatable
Input/Output Current	Continuous Stall Current: 7.4 A, Peak Stall Current: 26.0 A
Rated Speed	5000 RPM
