TECHNICAL SPECIFICATIONS

Introduction

The Beckhoff EL1904 EtherCAT Terminal is designed for comprehensive monitoring and signal processing, facilitating seamless integration into various automation systems. This 4-channel digital input module with cross-circuit detection and TwinSAFE support offers versatile usage in a compact design, making it suitable for a diverse range of industrial applications. Din rail mounting and an IP20 protection rating ensure easy installation and reliable operation in industrial environments.

Technical Specifications for EL1904

The EL1904 features four digital input channels that support 24VDC signals, enhancing its applicability in numerous industrial settings. TwinSAFE technology incorporated in the module guarantees safety by enabling the execution of safety-related tasks. Its compatibility with the EtherCAT system allows for high-speed communication and streamlined integration with other components in the automation network, demonstrating both flexibility and efficiency in its performance.

Setup and Operating Climate Conditions

Designed for optimal performance in industrial conditions, the EL1904 operates effectively within a broad temperature range. It withstands operational environments marked by fluctuating temperatures and variable humidity levels, ensuring reliability and durability. The module's compact form factor, suited for DIN rail mounting, facilitates efficient space usage in control cabinets, and adherence to IP20 standards underscores its robustness against particle ingress.

Component Details and Configuration

This module stands out for its intuitive design, allowing for straightforward installation and setup. The EL1904 is easily configured within automation systems, demonstrating its user-friendly interface and compatibility with standard industry practices. By supporting EtherCAT communications, it integrates smoothly with existing automation architectures, offering a versatile solution for digital input processing.

Additional Safety Measures

Incorporating TwinSAFE technology, the EL1904 extends additional security measures to industrial automation setups. This feature enhances the safety and reliability of operations, providing peace of mind and supporting compliance with stringent regulatory requirements. Integration into safety-oriented systems is made easier, highlighting the EL1904's commitment to safeguarding operations and personnel.

Request a Quote Today

Secure the EL1904 for your automation project and streamline your operations with high efficiency and reliability. Visit us to explore our vast selection and start transforming your industrial setup today. Order Now!
