Description

FANUC A06B-0032-B575

The FANUC A06B-0032-B575 is a reliable AC Servo Motor suitable for various industrial automation needs. It is part of the Alpha iF series designed by FANUC automation products company. The motor is an effective solution, featuring cutting-edge features and precise control capabilities. Its superior torque and speed modulation enhance its efficiency and productivity across various applications. The compact design and energy-efficient operation reduce the overall power consumption.

Electrical Specifications:

The FANUC A06B-0032-B575 AC Servo Motor operates on a voltage range of 200 to 230 V, producing a rated power of 0.9 kW. It provides a rated torque of 4.5 Nm with a speed of 2000 RPM. The motor uses an absolute encoder A32k ppr that delivers high-resolution feedback. The absolute encoder is critical for applications that need elevated precision and accuracy. It guarantees the motor can return to its original position even after a power outage, enhancing its reliability.

This servo motor by FANUC weighs 6.5 kg and has a taper shaft with a key. The taper shaft is designed conically to provide a more secure and accurate fit in mechanical applications. It uses a natural cooling method, offering a reliable, maintenance-free, cost-effective approach to regulating heat dissipation.

Safety Features:

The A06B-0032-B575 Servo Motor has several safety features to ensure its safe and efficient operation. The overload protection feature prevents damage from excessive current and torque, avoiding overheating and potential motor failure in overload conditions. The motor is equipped with an overheat alarm that helps maintain its temperature. The alarm will automatically trigger when the temperature exceeds the set threshold.

The short-circuit protection detects electrical faults and disconnects the motor's power supply, reducing the risk of fire and equipment failure. The motor incorporates ground fault interruption capability, which detects and responds to electrical leakage. The absolute encoder has a battery backup that retains position data even during power outages. Lastly, the motor includes an emergency stop button that immediately ceases operation during hazardous situations.

Operational Features:

The A06B-0032-B575 Servo Motor by FANUC provides superior digital feedback to ensure accurate positioning. The feedback system of this Servo Motor gives high-resolution, real-time data, which improves precision and control. This mechanism is critical to assuring the motor's functioning in precision-demanding environments. The A32k PPR encoder provides 32,768 pulses per revolution, which improves its feedback capabilities.

The motor produces a high-rated torque at elevated speeds, ensuring that the motor can execute demanding tasks efficiently and consistently. The design of the servo motor contains features that make maintenance easier, such as easily accessible components and a solid natural cooling mechanism. This motor is intended to offer accurate and consistent motion control, making it perfect for complicated applications that need coordinated movement across multiple axes.

Frequently Asked Questions:

Which industries commonly use the FANUC A06B-0032-B575 AC Servo Motor?

The FANUC A06B-0032-B575 AC Servo Motor is widely utilized in CNC machining, robotics, and industrial automation applications. The servo motor's ability to deliver rapid and accurate control saves downtime and improves throughput.

Is the FANUC A06B-0032-B575 suitable for high-precision tasks?

This servo motor is perfect for high-precision tasks because of its advanced digital feedback and high-resolution encoder. The motor performs complex tasks easily.

Can the FANUC A06B-0032-B575 AC Servo Motor be used in multi-axis systems?

The FANUC A06B-0032-B575 can be incorporated into multi-axis systems to control coordinated motion. The model is ideal for industrial automation applications.

Product Specifications Table

Attribute	Specification
Product Type	AC Servo Motor
Manufacturer	FANUC
Rated Power	0.9 kW
Rated Speed	2000 RPM
Voltage Range	200-230V
Rated Torque	4.5 Nm
Encoder Type	Absolute
Cooling Method	Natural Cooling
Weight	6.5 kg
High-Resolution Encoder	32,768 PPR
