TECHNICAL SPECIFICATIONS

FANUC A06B-0235-B100

The FANUC AC servo motor A06B-0235-B100 offers an ideal solution for powering the feed axes of machine tools, ensuring accurate control with reliable and efficient performance.

The IP65 rating is equipped on this A06B-0235-B100 model.offering reliable protection against dust and liquid damage. The first number ensures your device will remain shielded from particulate matter, while the second guarantees resistance to water infiltration.

Technical Description of A06B-0235-B100:

The advanced model A06B-0235-B100 offers excellent precision with its high€“resolution pulse coder, weighing just 9.6 kilograms and powered by a 184 V input voltage. Accurately positioning is made easy thanks to the standard feature of this motor.

The motor A06B-0235-B100 offers an impressive maximum rpm 4000 and a special frequency rate of 267Hz. Additionally, its unique magnetic pole shape improved to reduce torque ripple for unparalleled smoothness in rotation performance.

This A06B-0235-B100 FANUC motor packs an impressive 2.5 kW of power with a low current draw of 8.3 A, all while maintaining maximum output torque thanks to its reduced rotor inertia design - making it exceptional at providing efficient and speedy acceleration performance.

A safe and reliable 3-phase voltage supply of between 200 to 240 V and a frequency of 50/60 Hz is essential for optimal operation. Furthermore, we must utilize an advanced thermal function to ensure that the motor temperatures remain within acceptable limits by continuously monitoring current levels.

The A06B-0235-B100 model has an insulation class of F and a power factor of 97%, while the oil seal on its shaft protects against the intrusion of foreign particles like oil.

The A06B-0235-B100 model creates an impressive 8 Nm of torque with a mere 11 A current draw. FANUC's specially designed stator seal prevents external liquids from compromising the motor's performance, ensuring comprehensive waterproofing through robust connectors.

Operating and Installation Ambient Conditions:

The acceptable operating range for the motor is between -10 and 40°C. When running in high-temperature environments, decrease the output power to prevent overheating.

The A06B-0235-B100 motor is designed to be installed at maximum heights up to 1,000 meters above sea level without any added requirements. It can even operate safely in high altitudes if the ambient temperature drops by one degree Celsius for every 100-meter increase beyond 1000 m - with no additional measures needed.

Standard Cautions:

Always use a specified amplifier to supply the motor voltage for optimal performance. Without it, the over-application of commercial power sources may damage its windings and render it inoperable.

Poor handling of the A06B-0235-B100 motor can result in serious damage, reducing its optimal performance. To maintain the integrity and longevity of your machine's parts, take extra care during transportation; never attempt to lift it by gripping any plastic pieces or wiring components.

To ensure optimal motor storage, make sure your environment is dry and at room temperature. Avoid humid areas and hot spots - this can lead to component breakdowns over time! Keep the motors' shaft horizontal with the terminal box facing upward for best results.

Before using the A06B-0235-B100 motor, conduct a winding resistance and insulation check. It will ensure its proper functioning. Should the motor be stored for an extended period, take extra caution as this could lead to deterioration due to environmental conditions or age.
