TECHNICAL SPECIFICATIONS

FANUC A06B-0267-B605

This servo motor A06B-0267-B605 is an ideal choice for a feed axis. It suits large-scale operations requiring high speed, precision, and smaller machine tools.

The motor A06B-0267-B605 boasts an impressive maximum output torque and intermediate rotor inertia, resulting in exceptional acceleration capabilities.

Technical Description of A06B-0267-B605:

This advanced servo motor A06B-0267-B605 offers remarkable power and efficiency, generating 4.5 kW with a mere 14 A current draw thanks to its state-of-the-art neodymium ferrite magnet design. The technology behind this powerful yet small unit facilitates increased usability in limited spaces such as those typically used for machine tools.

FANUC's combination of waterproof connectors and a specialized stator seal offers dependable protection against liquid infiltration so that coolant stays where it belongs.

The A06B-0267-B605 model demonstrates superior stall torque of 30 Nm while consuming a minimal amount. We extensively applied innovative modifications to the magnetic pole shape to minimize torque ripple and create an incredibly smooth rotation experience.

The A06B-0267-B605 servo motor has a remarkable performance capability of 2000 revolutions per minute and 133 Hz frequency. It also comes equipped with thermal surveillance to safeguard against an excessive temperature increase by watching for unnatural currents within the system.

This model A06B-0267-B605 is totally dust and liquid-proof, with an IP65 rating. Its high winding density lowers heat generation during rapid rotation to the absolute minimum due to its optimally shaped core design - allowing for wide, uninterrupted operation.

The model A06B-0267-B605 features an advanced insulation class of F and a superior power factor of 98%. A specially-sealed shaft safeguards the motor from liquids like oil, protecting it against foreign matter.

This A06B-0267-B605 motor is equipped with a high-resolution pulse coder, which ensures precision positioning. The power supply requirements are 200-230 V and 50/60 Hz, respectively, for optimal performance.

Ambient Conditions- Operating:

To ensure optimal performance, the motor A06B-0267-B605 should operate between -10 to 40°C and reduce the output power when working at higher temperatures. Doing so will help prevent overheating of the model beyond its designed threshold level.

General Wiring and Handling Precautions:

When handling motor A06B-0267-B605, your safety needs to take appropriate measures. Appropriate clothing and accessories, such as gloves or safety shoes, should be worn when working with the machine to avoid any potential risks associated with projecting parts or electric shocks. Wet hands must also remain away from the motor to prevent dangerous electrical accidents due to the extreme power levels involved.

You must isolate the power source Before connecting the motor to electrical wiring. Failing to take proper precautions can quickly lead down a dangerous path; if you do not take grounding steps with the utmost caution and attention, the risk of electric shock will increase exponentially.

Be sure that once you've established all necessary safety protocols, including connecting the machine's terminal box ground wire firmly into position, your project will go forward without risk of harm or damage.

For safety and optimal performance, it is important to ensure the secure connection of power wires with short bars at the terminal block. Ensuring tight connections will prevent potentially hazardous incidents such as overheating that could cause a fire or disconnection, which may result in serious damage, including ground fault, short circuit, and electric shock.
