Mitsubishi FX2NC-4DA

Mitsubishi Fx2Nc-4Da

Mitsubishi FX2NC-4DA

The Mitsubishi FX2NC-4DA is a digital-to-analog converter (DAC) module specifically engineered to improve the functionality of Mitsubishi's FX series programmable logic controllers (PLCs). It is indispensable for various industrial automation applications, offering precise and dependable analog output capabilities. This module is renowned for its high-performance capabilities, robust design, and compact size, rendering it an ideal choice for intricate control systems.

Technical Specifications:

The Mitsubishi FX2NC-4DA is a prime example of a digital-to-analog converter. Eight input/output terminals can be powered by either an internal 5V DC at a 30 mA source or an external 24V DC at a 200 mA source. The module is a small box with dimensions of 24 mm x 90 mm x 89 mm and a weight of 0.13 kg.

The FX2NC-4DA's analog output range includes a voltage output from -10V DC to 10V DC and a current output from 0 mA to 20 mA. The digital input's 11 bits + sign bit allow for a voltage output resolution of 5 mV and a current output resolution of 20 ?A.

The module is accurate within ±0.5% at 25 °C ± 5 °C and ±1.0% between 0 °C and 55 °C at 20V, ignoring load changes. Four channels convert in 2.1 ms, ensuring fast and precise data processing. In the Mitsubishi FX2NC-4DA, a photocoupler isolates the analog output and PLC, and a transformer isolates the power supply and analog output.

This separation improves the system's reliability and safety by reducing interference and assuring steady functioning. The module has 8 I/O points and is compatible with FX2NC and FX3UC Series PLCs.

Power Supply Specifications:

The analog circuits are driven by a 24 V DC ±10%, 130 mA external source. An extension port from the PLC central unit supplies 5 V DC, 30 mA, to the digital circuitry.

The analog output range is -10V DC to 10V DC and 0 mA to 20 mA. The module offers a 5 mV voltage output and a 20 ?A current output resolution. The FX2NC-4DA has an accuracy of ±0.5% at 25 °C ± 5 °C and ±1.0% from 0 °C to 55 °C at 20V, eliminating load changes.

Four-channel data processing is efficient, with a 2.1 ms conversion speed. A photocoupler isolates the analog output and PLC, whereas a transformer isolates the power supply and analog output.

Safety Instructions:

Safety is important with the Mitsubishi FX2NC-4DA. Local and national requirements require qualified engineers to operate the module. They should comprehend all automated equipment safety issues.

Engineers must follow these standards and be trained to handle, commission, and service products safely. Similarly, all operators of the finished product must be trained to operate it safely and follow safety regulations.

Advanced features and durable design make the module a reliable component for key industrial applications, ensuring automation process efficiency and smoothness. Due to its exact analog output and robust safety measures, the Mitsubishi FX2NC-4DA is a great choice for increasing Mitsubishi PLC capabilities in many industrial situations.

Frequently Asked Questions:

What is the power consumption of the Mitsubishi FX2NC-4DA module?

The Mitsubishi FX2NC-4DA module uses 5V DC at 30 mA internally and 24V at 200 mA externally. The power needs to ensure efficient operation within the constraints.

How many input/output points does the Mitsubishi FX2NC-4DA accommodate?

The Mitsubishi FX2NC-4DA accommodates eight input/output connections, enabling flexible integration of various automation systems.

What is the resolution of the Mitsubishi FX2NC-4DA's outputs?

The Mitsubishi FX2NC's voltage output has a resolution of 5 mV, while the current output has a resolution of 20 ?A. These resolutions guarantee precise control over automation duties.

Product Specifications Table

Attributes Specification
Manufacturer Mitsubishi
Product Type Digital to analog converter
Number of I/O 8
Internal Power Supply 5V DC, 30 mA
External Power Supply 24V DC, 200 mA
Mass 0.13 kg
Dimensions (W x H x D) 24 mm x 90 mm x 89 mm
Analog Output Range Voltage: -10V DC to 10V DC, Current: 0 mA to 20 mA
Resolution Voltage: 5 mV, Current: 20 ?A
Conversion Speed 2.1 ms for 4 channels

Mitsubishi FX2NC-4DA

Regular price
Sale price
$4,939.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Description

Mitsubishi FX2NC-4DA

The Mitsubishi FX2NC-4DA is a digital-to-analog converter (DAC) module specifically engineered to improve the functionality of Mitsubishi's FX series programmable logic controllers (PLCs). It is indispensable for various industrial automation applications, offering precise and dependable analog output capabilities. This module is renowned for its high-performance capabilities, robust design, and compact size, rendering it an ideal choice for intricate control systems.

Technical Specifications:

The Mitsubishi FX2NC-4DA is a prime example of a digital-to-analog converter. Eight input/output terminals can be powered by either an internal 5V DC at a 30 mA source or an external 24V DC at a 200 mA source. The module is a small box with dimensions of 24 mm x 90 mm x 89 mm and a weight of 0.13 kg.

The FX2NC-4DA's analog output range includes a voltage output from -10V DC to 10V DC and a current output from 0 mA to 20 mA. The digital input's 11 bits + sign bit allow for a voltage output resolution of 5 mV and a current output resolution of 20 ?A.

The module is accurate within ±0.5% at 25 °C ± 5 °C and ±1.0% between 0 °C and 55 °C at 20V, ignoring load changes. Four channels convert in 2.1 ms, ensuring fast and precise data processing. In the Mitsubishi FX2NC-4DA, a photocoupler isolates the analog output and PLC, and a transformer isolates the power supply and analog output.

This separation improves the system's reliability and safety by reducing interference and assuring steady functioning. The module has 8 I/O points and is compatible with FX2NC and FX3UC Series PLCs.

Power Supply Specifications:

The analog circuits are driven by a 24 V DC ±10%, 130 mA external source. An extension port from the PLC central unit supplies 5 V DC, 30 mA, to the digital circuitry.

The analog output range is -10V DC to 10V DC and 0 mA to 20 mA. The module offers a 5 mV voltage output and a 20 ?A current output resolution. The FX2NC-4DA has an accuracy of ±0.5% at 25 °C ± 5 °C and ±1.0% from 0 °C to 55 °C at 20V, eliminating load changes.

Four-channel data processing is efficient, with a 2.1 ms conversion speed. A photocoupler isolates the analog output and PLC, whereas a transformer isolates the power supply and analog output.

Safety Instructions:

Safety is important with the Mitsubishi FX2NC-4DA. Local and national requirements require qualified engineers to operate the module. They should comprehend all automated equipment safety issues.

Engineers must follow these standards and be trained to handle, commission, and service products safely. Similarly, all operators of the finished product must be trained to operate it safely and follow safety regulations.

Advanced features and durable design make the module a reliable component for key industrial applications, ensuring automation process efficiency and smoothness. Due to its exact analog output and robust safety measures, the Mitsubishi FX2NC-4DA is a great choice for increasing Mitsubishi PLC capabilities in many industrial situations.

Frequently Asked Questions:

What is the power consumption of the Mitsubishi FX2NC-4DA module?

The Mitsubishi FX2NC-4DA module uses 5V DC at 30 mA internally and 24V at 200 mA externally. The power needs to ensure efficient operation within the constraints.

How many input/output points does the Mitsubishi FX2NC-4DA accommodate?

The Mitsubishi FX2NC-4DA accommodates eight input/output connections, enabling flexible integration of various automation systems.

What is the resolution of the Mitsubishi FX2NC-4DA's outputs?

The Mitsubishi FX2NC's voltage output has a resolution of 5 mV, while the current output has a resolution of 20 ?A. These resolutions guarantee precise control over automation duties.

Product Specifications Table

Attributes Specification
Manufacturer Mitsubishi
Product Type Digital to analog converter
Number of I/O 8
Internal Power Supply 5V DC, 30 mA
External Power Supply 24V DC, 200 mA
Mass 0.13 kg
Dimensions (W x H x D) 24 mm x 90 mm x 89 mm
Analog Output Range Voltage: -10V DC to 10V DC, Current: 0 mA to 20 mA
Resolution Voltage: 5 mV, Current: 20 ?A
Conversion Speed 2.1 ms for 4 channels
