Mitsubishi GT1672-VNBA

The Mitsubishi GT1672-VNBA is a high-performance graphical control terminal that improves industrial automation systems. It has extensive capabilities, a sturdy build, and a user-friendly interface, making it excellent for complex applications. With a streamlined design and dependable performance, this model meets a wide range of operational needs with precision and efficiency.

Technical Specifications:

The GT1672-VNBA is compatible with the GT Works3 Version 1.17 T or later software suite. This guarantees seamless integration with existing systems and grants access to the most recent features. The unit is lightweight and durable, suitable for various installation environments, weighing only 2.3kg.

The panel cutaway dimensions are 289 x 200mm, which makes installation a breeze. The GT1672-VNBA boasts a compact form factor that does not sacrifice functionality, with external dimensions of 397 x 296 x 61mm.

The terminal can withstand severe industrial conditions, providing IP67 and IP2X protection inside the enclosure (4, 5). The built-in siren output emits a single tone with a variable duration and improves operational alerts.

Thanks to its 11 MB built-in flash memory, the GT1672-VNBA provides ample storage capacity for data and applications. Its detection latency is 0 to 4 seconds, which enables precise monitoring and control. The power supply voltage is 24V DC, guaranteeing dependable and consistent power for optimal performance.

The Mitsubishi GT1672-VNBA offers various communication interfaces, such as Ethernet, RS-232, and RS-422/485, which provide adaptable connectivity options for various industrial environments. The display brightness can be adjusted to a maximum of 800 cd/m ² to ensure visibility in various illumination conditions.

Detection Specifications:

Due to its 1-meter detection distance, the GT1672-VNBA is well-suited for close-range applications. It can detect temperature discrepancies between the human body and ambient air of 4 °C or greater, guaranteeing dependable and precise functionality.

The GT1672-VNBA's analog resistive touch interface offers an intuitive and responsive user experience. The visual output is clear and detailed thanks to the 10.4-inch screen and 640 x 480 VGA resolution. The display measures 211 x 158 mm, providing a generous viewing area for intricate graphical data.

The terminal facilitates international operations by supporting various languages and character sets. Reliability is guaranteed in a variety of environmental conditions, as the operating temperature range is from 0 °C to 50 °C and the storage temperature range is from -20 °C to 60 °C.

Safety Precautions:

The GT1672-VNBA can rely on the optional GT15-BAT lithium battery in case of main power interruptions. This improves the system's resilience and ability to continue operations. The terminal has a temperature-detecting capability to keep everyone safe by monitoring the disparity between the user's core and ambient temperatures.

Because of its dust and water resistance, it is ideal for harsh industrial environments, protected by its IP67 exterior and IP2X interior enclosure classifications. Additionally, the terminal is designed to withstand mechanical vibrations with amplitudes of 0.075 mm, accelerations of 9.8 m/s ², and vibrations from 5 to 9 Hz.

Frequently Asked Questions:

What type of touch interface does the GT1672-VNBA use?

The GT1672-VNBA employs an analog resistive touch interface. This offers an intuitive and responsive user experience for industrial applications.

What are the external dimensions of the Mitsubishi GT1672-VNBA?

The GT1672-VNBA's external dimensions are 397 x 296 x 61mm. This modest form factor enables effortless installation in a variety of environments.

What is the GT1672-VNBA's internal flash memory capacity?

The GT1672-VNBA has 11 MB of internal flash memory, which ensures effective performance by providing adequate storage for applications and data.
