Indramat HDS02.2-W040N
Indramat HDS02.2-W040N
The HDS02.2-W040N HDS drive controller has a belonging from the well-known company Indramat Rexroth. It is an electrical and electronics manufacturing company capable of providing various control drives to be used in several industrial systems. The "W040N" typically indicates the power rating or configuration of the drive. They offer precise control over motor speed and position, making them ideal for demanding applications where accuracy and reliability are critical
Technical Specifications :
The Indramat HDS02.2-W040N drive operates at a rated control voltage input (UL) of 26 ±2%V. It has power consumption at the control voltage input, without holding brake and devoid of control at 20W, to underline its efficiency and economical operation. Moreover, it offers multiple communication interfaces, facilitating easy integration with other automation components and systems.
Operating within a rated input voltage of 530-670 V, this drive is engineered for fast performance in industrial domains. With a maximum input current (UL) of 37A to drive demanding applications, guaranteeing reliability under heavy loads.
It features a maximum output voltage (UL) of 500V across three phases, ensuring consistent power delivery. Its maximum output current (UL) of 20A and a maximum output frequency (UL) of 1000 Hz further attest to its capacity to handle dynamic and high-speed operations with robustness.
The drive weighs about 6.5 Kg and has a 498 mm height with 50 mm of width. Under continuous operation at maximum output, the drive manages power dissipation with a rating of 125W, shielding against overheating and sustaining performance and accuracy over long durations.
Operational and Installation Parameters:
It is suggested that 60/75 °C copper wire is suitable for this drive. When installation occurs, the controller's control electronics draw power through its connector, initiating a pathway from the supply unit and extending to the drive controller via integrated low-level-ribbon cable within the units.
Three power lines or wires are used for connecting the motor. In case a direct connection via wires becomes unfeasible, make the connection using tightly twisted supply lines of minimal length. Furthermore, maximum recommended ambient temperature for drive operation is 45 degrees centigrade for the desired functioning of the drive.
Safety Precautions:
It is necessary to thoroughly review all the accompanying materials before setting up or using the HDS02.2-W040N drive equipment. Utilize only Bosch Rexroth certified replacement components and accessories. Prior to handling electrical elements exceeding 50 V, disconnect the device from its power source to avoid injuries.
Implement measures to prevent accidental high voltage and current. Allow a 30-minute interval after powering down to ensure capacitors are fully discharged before commencing any work. Also, wear proper costumes to be safe from electrical shocks. Keep the drive in a neat and clean environment.
Frequently Asked Questions:
What are the dimensions of the drive HDS02.2-W040N?
The Indramat drive contains dimensions of 50 mm in width and has a height of 498 mm. These compact dimensions allow for easy integration into various industrial setups.
What is the HDS02.2-W040N drive's input voltage limit?
The drive HDS02.2-W040N has a limit for voltage ranging from 530 to 670 V for proper functioning. This range ensures stable operation under different power conditions.
How much three-phase output voltage does the HDS02.2-W040N drive give?
The Indramat HDS02.2-W040N drive gives a maximum voltage of 500 volts across a three-phase system in order to fulfill the desired requirement. This high output voltage is suitable for powering demanding industrial machinery.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Manufacturer | Bosch Indramat Rexroth |
| Width (mm) | 50 |
| Input Voltage (AC) | 530-670V |
| Output Voltage | 500 V |
| Output Current | 20 A |
| Humidity | up to 90% |
| Ambient Temperature Range | 0 - 45 degree centigrade |
| Frequency | 1000 Hz |
| Typical Power dissipation at continuous current | 125 W |
| Series | HDS |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Indramat HDS02.2-W040N
The HDS02.2-W040N HDS drive controller has a belonging from the well-known company Indramat Rexroth. It is an electrical and electronics manufacturing company capable of providing various control drives to be used in several industrial systems. The "W040N" typically indicates the power rating or configuration of the drive. They offer precise control over motor speed and position, making them ideal for demanding applications where accuracy and reliability are critical
Technical Specifications :
The Indramat HDS02.2-W040N drive operates at a rated control voltage input (UL) of 26 ±2%V. It has power consumption at the control voltage input, without holding brake and devoid of control at 20W, to underline its efficiency and economical operation. Moreover, it offers multiple communication interfaces, facilitating easy integration with other automation components and systems.
Operating within a rated input voltage of 530-670 V, this drive is engineered for fast performance in industrial domains. With a maximum input current (UL) of 37A to drive demanding applications, guaranteeing reliability under heavy loads.
It features a maximum output voltage (UL) of 500V across three phases, ensuring consistent power delivery. Its maximum output current (UL) of 20A and a maximum output frequency (UL) of 1000 Hz further attest to its capacity to handle dynamic and high-speed operations with robustness.
The drive weighs about 6.5 Kg and has a 498 mm height with 50 mm of width. Under continuous operation at maximum output, the drive manages power dissipation with a rating of 125W, shielding against overheating and sustaining performance and accuracy over long durations.
Operational and Installation Parameters:
It is suggested that 60/75 °C copper wire is suitable for this drive. When installation occurs, the controller's control electronics draw power through its connector, initiating a pathway from the supply unit and extending to the drive controller via integrated low-level-ribbon cable within the units.
Three power lines or wires are used for connecting the motor. In case a direct connection via wires becomes unfeasible, make the connection using tightly twisted supply lines of minimal length. Furthermore, maximum recommended ambient temperature for drive operation is 45 degrees centigrade for the desired functioning of the drive.
Safety Precautions:
It is necessary to thoroughly review all the accompanying materials before setting up or using the HDS02.2-W040N drive equipment. Utilize only Bosch Rexroth certified replacement components and accessories. Prior to handling electrical elements exceeding 50 V, disconnect the device from its power source to avoid injuries.
Implement measures to prevent accidental high voltage and current. Allow a 30-minute interval after powering down to ensure capacitors are fully discharged before commencing any work. Also, wear proper costumes to be safe from electrical shocks. Keep the drive in a neat and clean environment.
Frequently Asked Questions:
What are the dimensions of the drive HDS02.2-W040N?
The Indramat drive contains dimensions of 50 mm in width and has a height of 498 mm. These compact dimensions allow for easy integration into various industrial setups.
What is the HDS02.2-W040N drive's input voltage limit?
The drive HDS02.2-W040N has a limit for voltage ranging from 530 to 670 V for proper functioning. This range ensures stable operation under different power conditions.
How much three-phase output voltage does the HDS02.2-W040N drive give?
The Indramat HDS02.2-W040N drive gives a maximum voltage of 500 volts across a three-phase system in order to fulfill the desired requirement. This high output voltage is suitable for powering demanding industrial machinery.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Manufacturer | Bosch Indramat Rexroth |
| Width (mm) | 50 |
| Input Voltage (AC) | 530-670V |
| Output Voltage | 500 V |
| Output Current | 20 A |
| Humidity | up to 90% |
| Ambient Temperature Range | 0 - 45 degree centigrade |
| Frequency | 1000 Hz |
| Typical Power dissipation at continuous current | 125 W |
| Series | HDS |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
